Portable Holographic Visual Display for Trade Shows High-Impact 3D Visual Effects
Product Overview
Introducing the 3D Hologram Fan from Shenzhen ZXTLCD—a state-of-the-art solution for creating stunning, life-like holographic displays in mid-air. This innovative fan-based display technology projects high-definition visuals that appear to float effortlessly in space, transforming the way you present your brand, products, or content. Ideal for retail displays, exhibitions, and promotional events, the 3D Hologram Fan is designed to capture attention and inspire awe.
By combining rapid rotation with powerful LED technology, the 3D Hologram Fan brings your content to life in an entirely new way, creating immersive 3D holograms that can be seen from any angle.
Key Features
· Immersive 3D Holographic Projections: Project stunning 3D images, animations, or videos that seem to float in mid-air, offering an unparalleled visual experience.
· High-Resolution Display: Enjoy vivid, high-definition visuals with exceptional clarity and detail, enhancing your message and captivating your audience.
· Portable and Easy to Install: Lightweight and easy to move, this fan display is perfect for both temporary and permanent setups at trade shows, stores, and events.
· Efficient Power Consumption: Designed with energy efficiency in mind, the 3D Hologram Fan ensures you get maximum impact with minimal power usage.
· Durable Construction: Built to last, this display is crafted from high-quality materials for longevity and resilience in both indoor and controlled outdoor environments.
· Simple Content Upload: Effortlessly upload and manage your content using a simple interface, ensuring easy customization for different promotional campaigns or business needs.
|
Product Model
|
ZXTLCD--M6
|
|
Device System
|
Android Smart System
|
|
Main Control (Main Frequency)
|
AllwinnerA40I(Quad-core 1.2GHz)
|
|
Display Size
|
64.5*64.5CM
|
|
Device Thickness
|
8.5CM
|
|
Resolution
|
2800*896
|
|
Number of LED Chips
|
896
|
|
Viewing Angle
|
176°
|
|
Rated Power
|
175W/24V
|
|
Input Voltage
|
100-240VAC,50/60HZ
|
|
Storage Space
|
8GB
|
|
Video/Image Format
|
MP4/JPG,
|
|
Bluetooth audio output
|
Support
|
|
Remote control
|
Support
|
|
Refresh rate
|
3840MHz (2037 units of 1920MHz)
|
|
Video processing method
|
FPGA hardware processing
|
|
Splicing method
|
Supports local area network splicing / remote cloud splicing
|
|
Decoding method
|
Hardware decoding
|
|
Driver IC
|
Jichuang 2153
|
|
Splicing center point spacing
|
460mm
|
|
Content replacement method
|
Mobile APP, WEB end, PC
|
|
Software support system
|
Windows,IOS,Android
|
|
Color
|
Black
|
|
Weight
|
0.78KG
|
|
Transmittance
|
92%
|
|
Noise
|
50 decibels
|
|
Brightness
|
3000cd/m2
|
|
Frame Rate
|
24 frames per second
|
|
Revolutions
|
720/min
|
|
Functional Features
|
Supports point-to-point control, network remote control, clustering, text ball, image cube
|
|
Provides upload software
|
Free
|
|
Product Material
|
ABS+PC/AL
|
|
Theoretical Machine Lifespan
|
30,000 hours
|
|
Warranty Period
|
12 months
|
|
Packaging Size/Weight
|
Disassembled lamp board packaging size: Inner box (Size: 428*255*125mm, Weight: including device 2.10KG)
Outer box one (1 unit packed, Size: 438*135*270mm, Weight: including device 2.45kg)
Outer box two (6 units packed, Size: 438*390*535mm, Weight: including device 13.7KG)
|
|
Unpacked lamp board dimensions: Inner box (Size: 558*555*128mm, Weight: including device 2.50KG)
Outer box one (1 unit packed, Size: 590*568*160mm, Weight: including device 3.1kg)
Outer box two (4 units packed, Size: 570*570*530mm, Weight: including device 11.2KG)
|
|
Common application locations
|
Retail chain stores, shopping centers, restaurants, clubs/bars, 4S stores, gas stations, subway/train stations, airports, customs, elevator advertising, exhibitions, press conferences, ceremonial events, education, etc.
|
|
Pricing terms＊
|
Excluding tax, not including shipping
|
|
Battery capacity calculation
|
Estimated working time = battery capacity / (power / voltage * 1000)
For example: Estimated working time = battery capacity 1000mAh / (power 20W / voltage 24V * 1000)
= 1000mAh / (20W / 24V * 1000)
= 10000mAh / 830mA
= 12 hours
|
Why Choose the 3D Hologram Fan?
The 3D Hologram Fan offers a one-of-a-kind way to engage your audience. The high-definition holograms generated by the fan’s rotating blades will stop people in their tracks, ensuring that your messages or products are noticed. Perfect for retail, trade shows, and corporate events, this display brings your content into the spotlight, giving you the flexibility to showcase a variety of content—from brand advertisements to product demonstrations and interactive displays.
This display is designed to help your brand stand out in any space, offering unmatched visibility and engagement.
