Windows Interactive Self-Order Kiosk for Retail, QSR, and Entertainment Venues
Description:
The Interactive Self-Order Kiosk offers a modern, efficient solution for businesses in the retail, quick-service restaurant (QSR), and entertainment sectors. This self-service terminal allows customers to browse product catalogs, build customized orders, and complete transactions independently. By integrating advanced touchscreen technology and seamless POS system compatibility, the kiosk optimizes both customer experience and operational efficiency.
Key Features:
· High-Resolution Touchscreen: The kiosk features a large 21.5” full HD touchscreen, providing clear visuals and smooth touch responses, making navigation intuitive and engaging for users.
· Customizable UI and Branding: The kiosk interface is fully customizable, allowing businesses to align it with their brand identity. Whether it’s a specific color scheme, promotional content, or product recommendations, the system offers flexibility to meet your marketing goals.
· Comprehensive Payment Options: The kiosk supports various payment methods, including credit/debit cards, contactless payment options like NFC, mobile wallets (Apple Pay, Google Pay), and QR code payments, ensuring a secure and quick checkout experience.
· Seamless Integration with POS Systems: The kiosk integrates effortlessly with your existing POS system, enabling real-time order processing, inventory updates, and accurate transaction tracking, improving operational efficiency.
· Multilingual Support: The kiosk is equipped with multiple language options to cater to a global customer base, providing a more inclusive experience for international patrons.
· Built for Durability: Constructed with high-quality materials, the kiosk is designed to handle heavy use in high-traffic environments. Its durable build ensures reliability, even in busy retail stores or restaurants.
· Energy-Efficient Operation: Featuring LED backlighting, the kiosk operates with minimal power consumption, reducing operational costs while maintaining high-quality performance.
| LCD Panel Parameters |
Screen Size |
21.5 inch |
| Display area |
476.5(H) X 268(V)mm |
| Aspect Ratio |
16 : 9 |
| LCD Type |
a-Si TFT-LCD |
| Max Resolution |
1920 X 1080 |
| Display color |
16.7M , 72% NTSC |
| Brightness |
350 cd/㎡ |
| Contrast Ratio |
3000 :1 |
| Viewing angle(up/down/left/right) |
89/89/89/89 (Typ.)(CR≥10) |
| Response Time |
20ms |
| LCD Panel Life(hrs) |
60,000(hrs) |
| Field Frequency |
60Hz |
| PCAP Touchscreen Panel Parameters |
Touch style |
Projected Capacitive Touch screen |
| Touch points |
10 points |
| Cover Glass |
Physical toughened Morse magnitude 7 explosion-proof |
| Anti-microbial protection and Shatterproof Protection |
| Optically bonded 3mm glass for low parallax |
| The glass transmittance |
>88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% |
| Response speed |
< 6ms |
| Accuracy of touch |
More than 90% of the touch area ±2mm |
| Touch ways |
Fingers, touch pen |
| Output format |
The coordinate output |
| Clicks time |
Unlimited |
| The smallest touch size |
5mm |
| Long resistance |
Yes available |
| Touch Interfaces |
USB |
| Operating temperature & Humidity |
below10℃ ~ +50℃, ≤ 85%RH |
| Storage temperature & Humidity |
below20℃ ~ +60℃, ≤ 90%RH |
| Mini PC Parameters (Fan-less Industrial PC) |
CPU |
Intel Celeron J1900 |
| RAM |
8GB |
| SSD |
64GB |
| WIFI |
150Mbps 802.11n wifi integate |
| Network port |
RJ45, 10M/100M Adaptive Ethernet |
| Interface |
2 * RJ45 GB Ethernet |
| 2 * RS232 Serial Port |
| operating system |
Win10 or win11 optional |
| Onboard interface |
HDMI input |
1 |
| VGA input |
1 |
| DVI input |
1 |
| USB Type B or Any USB Type optional |
1 |
| Parts(Built-in) |
QR/Barcode Reader |
Can recognize 1D barcode and 2D barcode |
| Receipt Printer |
80mm Thermal printer with cutter |
| Power |
Power supply |
AC 100V~240V, 50/60Hz |
| The Max power loss |
≤ 45w |
| Standby power loss |
< 1W |
| Features |
Operating temperature |
0℃ ~ 50℃ |
| Storage temperature |
below10℃ ~ +60℃ |
| Accessories |
The length of Power Cable |
1.5m |
| The length of HDMI Cable |
2m |
| The length of USB-A to USB-B Cable |
1.5m |
| Versatile Mounting Solution |
Wall Mounted |
with walll mount bracket |
| Stand Holder(Optional) |
Movable, can be with wheels on the base, height is adjustable |
| Package size |
Machine body size |
Customized |
| Net weight |
Customized |
| Unit Package size |
585 X 380 X 110mm |
| The Gross weight of Unit Package |
50kg |
Benefits:
· Enhanced Customer Experience: By enabling self-service ordering, customers can place orders quickly and on their terms, reducing wait times and enhancing their overall experience. With no need to wait in long lines, customer satisfaction is boosted.
· Streamlined Operations: The kiosk helps reduce staff workload by automating the ordering and payment process. This allows employees to focus on other important tasks like customer service and food preparation.
· Increased Revenue Potential: The kiosk promotes upselling and cross-selling by offering product recommendations, enhancing average order value and encouraging customers to explore additional items.
· Improved Accuracy and Reduced Errors: With customers directly entering their orders into the system, the risk of mistakes is minimized, leading to more accurate orders and fewer customer complaints.
· Data Collection and Insights: The kiosk collects valuable data on customer preferences, order history, and buying habits, providing businesses with actionable insights to optimize product offerings and improve marketing strategies.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
