Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-SOK215ATJ
Description:
The Smart Self-Service Ordering Kiosk offers an innovative solution to streamline the customer ordering process in both retail and foodservice environments. With an intuitive interface and a wide range of customizable features, this kiosk allows customers to explore menus or product catalogs, place orders, and complete transactions independently. Designed for ease of use and efficiency, this kiosk enhances the customer experience while optimizing staff productivity and operational performance.
Key Features:
· High-Resolution Touchscreen Display: The kiosk features a crisp and responsive 17” full HD touchscreen, offering clear visuals and smooth touch interactions for a satisfying user experience.
· Customizable Ordering Interface: The kiosk’s interface can be fully personalized to match your brand’s style, enabling you to display tailored content, promotions, and product recommendations to your customers.
· Multiple Payment Options: With support for credit/debit card payments, mobile wallets (Apple Pay, Google Pay), QR codes, and even cash payments, the kiosk offers flexible, secure, and contactless payment methods.
· Real-Time Integration with POS Systems: The kiosk seamlessly integrates with your Point of Sale (POS) system, ensuring that orders are processed and inventory is updated in real-time, minimizing errors and enhancing efficiency.
· Multilingual Support: To cater to a diverse customer base, the kiosk supports multiple languages, making it easy for international customers to place orders or make purchases.
· Durable Construction for High-Traffic Areas: Built to endure the demands of high-volume environments, this self-service kiosk is made with robust materials designed for long-term, heavy use.
· Energy-Saving LED Technology: Incorporating energy-efficient LED backlighting, the kiosk helps reduce energy consumption, lowering operational costs and contributing to sustainability.
LCD Panel Parameters | Screen Size | 17 inch | |
Display area | 337.92(H) X 270.34(V)mm | ||
Aspect Ratio | 16 : 9 | ||
LCD Type | a-Si TFT-LCD | ||
Max Resolution | 1920 X 1080 | ||
Display color | 16.7M , 72% NTSC | ||
Brightness | 350 cd/㎡ | ||
Contrast Ratio | 3000 :1 | ||
Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
Response Time | 20ms | ||
LCD Panel Life(hrs) | 60,000(hrs) | ||
Field Frequency | 60Hz | ||
PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
Touch points | 10 points | ||
Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
Anti-microbial protection and Shatterproof Protection | |||
Optically bonded 3mm glass for low parallax | |||
The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
Response speed | < 6ms | ||
Accuracy of touch | More than 90% of the touch area ±2mm | ||
Touch ways | Fingers, touch pen | ||
Output format | The coordinate output | ||
Clicks time | Unlimited | ||
The smallest touch size | 5mm | ||
Long resistance | Yes available | ||
Touch Interfaces | USB | ||
Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
RAM | 8GB | ||
SSD | 64GB | ||
WIFI | 150Mbps 802.11n wifi integate | ||
Network port | RJ45, 10M/100M Adaptive Ethernet | ||
Interface | 2 * RJ45 GB Ethernet | ||
2 * RS232 Serial Port | |||
operating system | Win10 or win11 optional | ||
Onboard interface | HDMI input | 1 | |
VGA input | 1 | ||
DVI input | 1 | ||
USB Type B or Any USB Type optional | 1 | ||
Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
Receipt Printer | 80mm Thermal printer with cutter | ||
Power | Power supply | AC 100V~240V, 50/60Hz | |
The Max power loss | ≤ 45w | ||
Standby power loss | < 1W | ||
Features | Operating temperature | 0℃ ~ 50℃ | |
Storage temperature | below10℃ ~ +60℃ | ||
Accessories | The length of Power Cable | 1.5m | |
The length of HDMI Cable | 2m | ||
The length of USB-A to USB-B Cable | 1.5m | ||
Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
Package size | Machine body size | Customized | |
Net weight | Customized | ||
Unit Package size | 440 X 385 X 110mm | ||
The Gross weight of Unit Package | 50kg |
Benefits:
· Faster Service and Shorter Wait Times: By allowing customers to place orders and complete payments independently, the kiosk significantly reduces wait times and improves overall service speed, even during peak hours.
· Enhanced Customer Satisfaction: Customers enjoy greater control over their orders, allowing them to browse, customize, and purchase without needing assistance. This creates a smoother, more enjoyable experience.
· Improved Order Accuracy: The kiosk eliminates human errors by letting customers directly input their selections, ensuring greater accuracy and reducing the risk of mistakes in the order.
· Increased Sales and Revenue: The kiosk’s upselling and cross-selling features prompt customers to explore additional items, boosting average order values and contributing to higher sales.
· Data-Driven Insights: The kiosk collects valuable customer data, including purchasing patterns and preferences, which can be analyzed to inform marketing strategies, optimize product offerings, and improve customer engagement.
Applications:
· Quick-Service Restaurants (QSRs): Ideal for fast-casual dining, this kiosk allows customers to browse menu items, place orders, and make payments quickly, reducing queue times and improving service efficiency.
· Retail Stores: Customers can explore product catalogs, check availability, and place orders for items that are out of stock in-store, allowing for a seamless shopping experience across both physical and digital spaces.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
