In the modern advertising field, floor-standing outdoor advertising displays are rapidly gaining popularity. This 55-inch outdoor lcd signage not only boasts an excellent design but also integrates commercial intelligence, providing a convenient and efficient solution for various information displays.
Unique Peacock Blue Slim outdoor lcd signage: Make Your Advertising Stand Out
【Appearance and Design】
Its peacock blue exterior design not only gives the floor-standing advertising display a unique visual appeal but also makes it stand out in various environments. The clean, smooth lines create a combination of modernity and professionalism, greatly enhancing the advertising display.
【Multi-functional Applications】
This outdoor lcd signage is not limited to traditional image displays but also supports dynamic video advertisements in various formats, greatly expanding the diversity of product promotion. Features such as multi-screen split-screen playback, scrolling text, and timed on/off functions make advertising more flexible and free.
【Strict Environmental Requirements】
outdoor lcd signage must withstand changing natural environments, from scorching heat to freezing cold, from wind and rain to extreme temperatures, and must maintain stable performance. The peacock blue casing is robust and durable, and its IP65 protection rating provides excellent water and dust resistance.
【High-Brightness Display】
A high-brightness display screen is a key feature of outdoor advertising machines, effectively attracting pedestrian attention. This advertising machine uses an ultra-high-brightness LCD screen, maintaining a clear and bright image even under strong sunlight, ensuring maximum advertising effectiveness.
【Intelligent Management】
The remote monitoring and management system allows users to monitor the operating status of the advertising machine in real time and perform remote maintenance and management. Whether it's content updates or troubleshooting, it can be done anytime, anywhere, ensuring the advertising machine's continuous and efficient operation.
【Energy Saving and Environmental Protection】
The highly efficient and energy-saving design not only reduces energy consumption but also lowers the environmental impact. The hardware, circuitry, and software design all adhere to energy-saving and environmental protection principles, contributing to sustainable development.
【Application Scenarios】
Whether in commercial areas, city centers, or large event venues, this 55-inch outdoor advertising machine, whether floor-standing or freestanding, showcases its unique charm, bringing endless possibilities to various scenarios such as advertising and information dissemination.
The 55-inch outdoor lcd signage, a floor-standing model with a peacock blue exterior and intelligent commercial features, will provide your advertising with a brand-new visual experience, helping you stand out in a highly competitive market.
| 55-inch Android Outdoor All-in-One Unit (Air Conditioner Model) Specification Sheet | ||
| Specications | ||
| The containment structure | The material and feature of shell | IP66 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 55 inch |
| Display area | 1214mm(H) X 684mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 1920X 1080 | |
| Display color | 16.7M | |
| Brightness | 2000cd/㎡~2500 cd/㎡ | |
| Contrast Ratio | 4000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz | |
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | |
| Touch Overlay for Interactivity | Touch style | Projected Capacitive Touch screen |
| Touch points | 10 points | |
| Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
| Drawer-type Android Media Player box Configuration | Processor Chip | RK3399, six core |
| RAM | 4GB | |
| Flash Memory Card | 32GB | |
| Wifi and 4G | Yes | |
| Version | Android 9.0 | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
| HDMI | 1 | |
| USB | 2 | |
| Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
| Speakers | Dual side speakers for Audio | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month | |
| Outdoor OMC system(optional) | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
| Problem and staus monitoring software included. | ||
| Touble shooting by software included. | ||
| Use softwae Remote Check key working performance by Group | ||
| Unnormal work alarm generation | ||
| Built-in Air conditioner for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust internal temperature |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | 0℃ ~ 50℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 280W | |
| Product size / Net weight | To be determined | |
| Outer Package size and Gross weight | ||
