Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OF860BA
In today's competitive business world, the power of advertising and promotion is increasingly evident. This 86-inch glossy black air-conditioned outdoor lcd monitor not only boasts a large screen and high-definition image quality, but also maintains excellent performance in extreme outdoor environments, providing an excellent solution for advertising needs in various venues.
86-inch Custom-Made Vertical outdoor lcd monitor, Unfazed by Extreme Environments
The 86-inch glossy black air-conditioned outdoor lcd monitor is more than just an ordinary advertising display device; it's an industrial-grade product with outstanding performance. Its unique air-conditioning design provides multiple hardware advantages:
① Extreme Operating Temperature Range: From scorching 55℃ to frigid -40℃, the advertising display operates stably under various climatic conditions, ensuring information transmission is unaffected by weather.
② Intelligent Temperature Control System: Intelligent temperature control technology effectively prevents screen blackouts, extends the lifespan of internal electronic components, and ensures clear visibility of the LCD screen even under direct sunlight.
③ Superior Protection Performance: The entire advertising display has an IP65 protection rating, reliably protecting against wind, rain, and lightning, ensuring the safe operation of internal equipment.
The 86-inch custom-made vertical outdoor lcd monitor in glossy black excels in various scenarios.
The 86-inch glossy black air-conditioning model outdoor lcd monitor demonstrates outstanding performance in multiple scenarios:
Commercial Centers: Seamlessly integrates into the commercial center environment, enhancing brand promotion and attracting customer attention.
City Squares: The visual impact of the high-brightness large screen makes it a focal point in city squares, conveying important information.
Tourist Attractions: Against a picturesque backdrop, the advertising machine's high-definition image quality resembles a dynamic painting, attracting tourists' curious gaze.
Transportation Hubs: At busy traffic nodes, the advertising machine directly targets crowds, allowing brand information to spread rapidly.
The 86-inch glossy black air-conditioning model outdoor lcd monitor, with its superior performance and wide applicability, has become a powerful tool for modern advertising. Whether in the sweltering summer or the frigid winter, whether in the city or the countryside, it operates stably, safeguarding your brand promotion!
| 86-inch Android Outdoor All-in-One Unit (Air Conditioner Model) Specification Sheet | ||
| Specications | ||
| The containment structure | The material and feature of shell | IP66 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 85 inch |
| Display area | 1860mm(H) X 1046mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 3840 X 2160 | |
| Display color | 16.7M | |
| Brightness | 2500cd/㎡~3000 cd/㎡ | |
| Contrast Ratio | 4000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz | |
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | |
| Touch Overlay for Interactivity | Touch style | Projected Capacitive Touch screen |
| Touch points | 10 points | |
| Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
| Drawer-type Android Media Player box Configuration | Processor Chip | RK3399, six core |
| RAM | 4GB | |
| Flash Memory Card | 32GB | |
| Wifi and 4G | Yes | |
| Version | Android 9.0 | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
| HDMI | 1 | |
| USB | 2 | |
| Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
| Speakers | Dual side speakers for Audio | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month | |
| Outdoor OMC system(optional) | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
| Problem and staus monitoring software included. | ||
| Touble shooting by software included. | ||
| Use softwae Remote Check key working performance by Group | ||
| Unnormal work alarm generation | ||
| Built-in Air conditioner for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust internal temperature |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | 0℃ ~ 50℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 500W | |
| Product size / Net weight | To be determined | |
| Outer Package size and Gross weight | ||
Multiple Forms of Content Playback: Unlike traditional printed media with one-time advertisements, Outdoor LCD Video Signs supports various forms of content playback, including videos, music, images, documents, and more.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
