13.3 inch Embedded Industrial Linux HD LCD All-in-One Computer

13.3 inch Embedded Industrial Linux HD LCD All-in-One Computer

13.3 inch industrial LCD computer

Linux all-in-one kiosk computer

embedded HD self-ordering kiosk

Place of Origin:

Guangdong, China

Brand Name:

ZXTLCD

Certification:

CE/Rohs/FCC

Model Number:

ZXTLCD-RM133SL

Chat Now
Request A Quote
Product Details
Screen Size:
13.3 Inch
Operating Temperature:
0°C To 50°C
Power Supply:
AC 100~240V, 50hz-60hz
Panel Type:
BOE Original A+ Grade IPS
Resolution:
1920 X 1080
Brightness:
350cd/m²
View Angle:
178°/178° (H/V)
Power Consumption:
80W
Cabinet Material:
Metal Case + Glass
Touch Screen:
10-point Capacitive Touch Screen
NFC Reader/scanner/QR Reader:
Support, Built-in
80mm Thermal Printer:
Support, Built-in
Passport Scanner:
Optional
POS Terminal Installation:
Resever Space
Application:
Hospitality, Hotel And Catering
Protype:
Desktop / Floor Standing /wall Mounted(Optional)
Highlight:

13.3 inch industrial LCD computer

,

Linux all-in-one kiosk computer

,

embedded HD self-ordering kiosk

Payment & Shipping Terms
Minimum Order Quantity
1
Price
negotiable
Packaging Details
wooden case, carton, flight cases are optional
Delivery Time
3-5 working days
Payment Terms
L/C,T/T,MoneyGram,Western Union
Supply Ability
2000 pcs per month
Product Description

13.3 inch Embedded Industrial Linux HD LCD All-in-One Computer

Embedded Industrial All-in-One Screen for Self-Service Terminals

With the advancement of smart city and digital government initiatives, self-service terminals have become essential tools for information interaction in government agencies, commercial outlets, and public service venues. As the core display module, the embedded industrial all-in-one screen for self-service terminals provides a solid foundation for reliable terminal operation through its high integration, stability, and expandability.

13.3 inch Embedded Industrial Linux HD LCD All-in-One Computer 0

Industrial-Grade Design for Stable Operation
The screen utilizes industrial-grade A-Spec LCD panels, delivering high-definition visuals, high brightness, and wide viewing angles to ensure clear information presentation under various lighting conditions.

Rich Interfaces for Easy System Integration
Equipped with multiple industrial ports including HDMI, VGA, USB, serial port, and RJ45 Ethernet port.

Compatible with mainstream operating systems (Windows, Linux, Android, etc.), meeting connectivity requirements for various main control boards or embedded hosts.

Supports expansion modules such as IC/ID card readers, QR code scanners, cameras, microphones, and fingerprint recognition devices to adapt to diverse functional scenarios.

13.3 inch Embedded Industrial Linux HD LCD All-in-One Computer 1

Wide-Ranging Applications
Widely deployed in hospital registration/payment kiosks, bank self-service terminals, government service machines, airport self-check-in systems, smart parcel lockers, mall information kiosks, and station self-service ticket vending machines.

Customization Options
Supports customization of panel size (e.g., 10.1/15.6/18.5/21.5/23.6/27/32/43 inches), bezel material, and color to meet specific project requirements.

13.3 inch Embedded Industrial Linux HD LCD All-in-One Computer 2

The embedded industrial all-in-one screen for self-service terminals is not merely an information display medium but an intelligent bridge connecting people and services. With high performance, broad compatibility, and sleek design, it enables smarter, more efficient, and more user-friendly terminal experiences.

LCD Panel Parameters Screen Size 13.3 Inch
Display Area 294 mm.(Height) X 165.5(Width)mm.
Aspect Ratio 16 : 9
LCD Type a-Si TFT-LCD Monitor
Maximum Resolution 1920 X 1080
Display Color 262K, 45% NTSC
Brightness 220cd/m²
Contrast Ratio 800 : 1
Viewing Angle (Up/Down/Left/Right) 85°/85°/85°/85° (Type)(CR≥10)
Response Time 30ms
LCD Panel Lifespan (Hours) 60,000(Hour.)
Field Frequency 60Hertz
Internal computer configuration
(Choose one of two)
CPU i5-4310M Generation 4, Dual-Core Four Threads, Main frequency can reach up to 2.7GHz I5-6100T Generation 6, Dual-Core Four Threads, Main frequency can reach up to 3.2GHz
Graphics Card Integrated Graphics Card Intel® HD 4600 Integrated Graphics Card Intel® HD 530
RAM 4GB 8GB
Storage Memory Capacity 128GB 256GB
OS Linux Linux
Wi-Fi Built-in Speed 150Mbps 802.11n wifi Integrated Speed 150Mbps 802.11n wifi Integrated
Media Format Video Format wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc.
Audio Format MP3, WMA
Photo Format BMP, JPEG, PNG, GIF etc.
Onboard Interface Network port RJ45 X 1, 10M/100M Adjustable Ethernet
HDMI 1
USB 4
Power Power Supply Alternating Current 100V~240V, 50/60Hz
Maximum Power Loss ≤ 25 Watt
Standby Mode Power Loss < 1 Watt
Features Operating Temperature 0℃ ~ 50℃
Storage Temperature Below 10℃ ~ +60℃
Package Size Device Dimensions 339 X 219 X 51.7mm.
Net Weight 3 Kilogram
Package Size 38.9 X 27.4 X 11Centimeter
Gross Package Weight per Unit 4 Kilogram
