With the rapid development of artificial intelligence and robotics, the catering industry is undergoing a profound transformation. The 32-inch ordering robot has not only attracted considerable attention with its unique hardware design but also brought a new operating model to restaurants through its flexible and diverse application scenarios.
![]()
The 32-inch ordering robot adopts advanced industrial design, ensuring stability and durability even under high-intensity use. Its core components include a 32-inch high-definition display (1080P full HD resolution), supporting wide viewing angles and providing clear visuals even in complex lighting environments. The screen surface features an anti-fingerprint coating, reducing stains and fingerprints, keeping it clean and tidy at all times. The bottom of the device is equipped with high-precision LiDAR and ultrasonic sensors, enabling real-time perception of the surrounding environment, collision avoidance, and autonomous navigation. The robot's casing is made of high-strength aluminum alloy, providing excellent heat dissipation and pressure resistance, ensuring stable operation of internal electronic components over long periods.
![]()
The 32-inch ordering robot is not only suitable for indoor environments but can also function effectively in outdoor settings. For example, in outdoor cafes or fast-food restaurant seating areas, robots can serve as mobile ordering terminals, allowing customers to order and pay via touchscreen without having to wait in line inside. Furthermore, robots can also function as information kiosks in large shopping malls and airport waiting areas; simply changing the software system transforms them into touchscreen kiosks, and accessories from the ordering machines can also be used for these kiosks.
![]()
Beyond its powerful hardware, the 32-inch ordering robot supports highly customizable designs. Businesses can personalize it by choosing different colors, patterns, and even materials to match their brand image. For example, high-end restaurants can choose a metallic shell and a simple, elegant design to match their upscale positioning; while children's themed restaurants can use cartoon characters and vibrant colors to attract children's attention.
In addition, detachable decorations or billboards can be installed on the top of the ordering robot to display promotional information or brand logos. This flexibility not only enhances brand recognition but also effectively improves advertising results. For businesses seeking uniqueness and brand personalization, the 32-inch ordering robot is undoubtedly an ideal choice.
![]()
![]()
The 32-inch ordering robot, with its superior hardware design, adaptability to various complex environments, and highly customizable appearance options, has become a highlight in the modern catering industry. Whether it's the autonomous navigation achieved through a precise environmental perception system or the robust and durable shell design ensuring stable operation over extended periods, this device demonstrates its powerful application potential. For businesses seeking to improve customer experience and operational efficiency, the 32-inch ordering robot is undoubtedly a worthwhile investment.
| LCD Panel Parameters | Screen Size | 32 inch | |
| Display area | 698(H) X 391.8(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 832 X 530 X 150mm | ||
| The Gross weight of Unit Package | 50kg | ||
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
