Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-SOK035
In diverse service scenarios such as catering, retail, and government services, higher demands are placed on the customization flexibility, delivery speed, and operational stability of self-service terminals. The new generation of all-in-one self-service terminals, with its rapidly replaceable modular design, industrial-grade powerful performance, and high-definition visual experience at its core, truly realizes a new service paradigm of "on-demand customization, rapid delivery, and stable operation," becoming a reliable engine driving the self-service upgrade of various industries.
The terminal adopts an innovative architecture with rapidly replaceable boards, significantly improving customization efficiency and delivery agility. The newly developed modular area supports flexible selection and rapid installation of various peripheral modules according to customer needs, without the need for overall reconstruction or lengthy debugging:
High-definition camera module: for facial recognition, security monitoring, or visual interaction;
Receipt printer module: built-in thermal printer for instant voucher output;
Metal keyboard module: provides physical button input, adaptable to special environments or high-frequency operation;
ID card reader module: quickly reads second-generation ID card information, suitable for government, hotels, hospitals, and other scenarios;
Card swiping/barcode scanning module: supports multiple recognition methods such as IC cards, QR codes, and barcodes.
This "module library" style customization solution significantly shortens the delivery cycle of customized products. Customers can combine the required functions like building blocks, truly achieving customization and rapid deployment within a week.
The device features a built-in low-power industrial-grade motherboard with powerful computing performance and excellent anti-interference capabilities. Its professional heat dissipation design and fanless architecture ensure quiet and low-power operation, even under high load and multi-tasking.
The terminal has undergone rigorous environmental testing, resisting various complex factors such as signal interference, strong light interference, and voltage fluctuations. It can operate stably 24/7 in various harsh environments, perfectly adapting to challenging scenarios such as outdoor use, transportation hubs, factory parks, and medical institutions.
III. High-Definition Vision: Original Factory Screen, True and Natural Colors Utilizing an original factory-packaged high-definition A-grade display screen with a resolution of 1080P, coupled with multi-layer optical protection technology, the image is clear, sharp, and the colors are vibrant and rich, providing true-to-life reproduction. The screen has high brightness characteristics, ensuring clear visibility even in strong indoor and outdoor environments, providing customers with a comfortable and intuitive interactive experience.
This modular intelligent self-service ordering machine is not only a breakthrough in hardware technology integration but also a profound response to the industry's customized needs and operational stability challenges. Its modular design solves the problems of slow and costly customization, while industrial-grade reliability ensures uninterrupted service across all time zones, enhancing user satisfaction with a high-definition interactive experience. For various enterprises and institutions that are advancing the digitalization and intelligentization of services, it is becoming a smart service node that can be quickly implemented and trusted long-term.
| LCD Panel Parameters | Screen Size | 17 inch | |
| Display area | 337.92(H) X 270.34(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 440 X 385 X 110mm | ||
| The Gross weight of Unit Package | 50kg | ||
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
