Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-SOK031
In today's retail industry, facing the dual pressures of peak customer traffic and high labor costs, self-checkout machines, with their simplified operation, flexible deployment, and intelligent marketing capabilities, are becoming a key tool for optimizing store operations and enhancing customer experience. It's not just a change in checkout methods, but a smart reshaping of shopping flow and service processes through technological means.
![]()
Self-checkout machines simplify the traditionally complex checkout process into three intuitive steps, requiring no human intervention:
Scan Product: Customers easily scan product barcodes using a built-in or handheld scanner.
Mobile Payment: Complete secure and fast payments using various mobile payment methods such as barcode scanning or facial recognition.
Print Receipt: The system automatically prints a receipt, completing the transaction.
This process design greatly reduces the learning curve for customers, especially appealing to younger and tech-savvy users. It effectively alleviates congestion at checkout counters during peak hours, shortens waiting times, and directly improves customer satisfaction.
![]()
The equipment features an intelligent advertising playback mode. When not in checkout mode, the screen automatically switches to an advertising interface, continuously displaying brand promotions, sales events, new product recommendations, or public service announcements. This function transforms previously idle terminal screens into valuable digital marketing billboards, helping merchants achieve precise reach and atmosphere creation for in-store advertising without incurring additional costs, thereby enhancing the overall commercial value of the store.
![]()
![]()
The most effective operating model is a dual-track approach of "human checkout + self-service checkout." During peak hours, self-service checkouts effectively divert customers who are familiar with the operation and purchase fewer items, reducing the pressure on human checkout counters and avoiding long queues. This collaborative model not only improves overall checkout efficiency but also allows cashiers to focus more on handling complex transactions or providing more personalized service, optimizing manpower allocation.
![]()
The introduction of self-service checkouts marks a shift in retail services from "human-centric" to "human-machine collaboration-centric." It solves efficiency bottlenecks during peak hours through technological means, adapts to diverse spatial constraints through flexible deployment, and creates additional value through value-added advertising functions. In today's increasingly competitive retail environment, deploying self-checkout machines is not only an efficiency upgrade but also an innovation in service concepts and business models, helping merchants find the optimal balance between cost and experience to win customer favor.
| LCD Panel Parameters | Screen Size | 32 inch | |
| Display area | 698(H) X 391.8(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 832 X 530 X 150mm | ||
| The Gross weight of Unit Package | 50kg | ||
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
