With the accelerated digital transformation of the restaurant industry, a powerful, user-friendly, and highly customizable self-service ordering kiosk has become a key piece of equipment for restaurants to improve operational efficiency and optimize customer experience. We offer you more than just a machine; we provide a smart restaurant solution integrating hardware durability, functional flexibility, and software personalization.
ZXTLCD's modular self-service ordering kiosk features a simple and modern design, specifically designed for high-intensity commercial environments.
Rugged and Durable: Continuing our high-quality customized metal casing (optional cold-rolled steel, aluminum alloy, etc.), the equipment ensures stable operation in high-traffic areas and effectively protects internal precision components.
Modular Design: The core innovation lies in the modular structure. Each functional component adopts a detachable design for easy maintenance and upgrades. You can flexibly select or replace different modules, such as barcode scanners, card readers, and cameras, according to the restaurant's real-time needs, achieving "one machine for multiple uses, adaptable to changing circumstances."
Built-in Receipt Printer: Integrates a high-speed thermal printer, allowing customers to instantly obtain a receipt or order details after completing their order and payment. This seamless process reduces waiting time and enhances the overall service experience.
We understand that every restaurant is unique, therefore, we incorporate the concept of "customization" throughout our products.
Customized Hardware Functions
In addition to standard touchscreens and printers, we offer a wealth of expandable module options. Whether adding contactless payment (NFC/facial recognition), membership card recognition, or connecting to a kitchen display system (KDS), our engineering team can tailor a hardware integration solution to ensure that the functionality perfectly matches your operational processes.
Deeply Customized Software and Interface
Customized Ordering Process: From eye-catching advertising pages to clear dine-in/takeout selection pages, detailed menu pages with item numbers, and finally the shopping cart checkout page, the entire interactive process can be personalized and adjusted according to your brand style and operational logic.
Flexible Menu Management: Supports the "Custom Menu" function. You can easily add seasonal new products, daily specials, or signature (set meals) in the backend at any time, providing customers with a wider range of choices and showcasing them through beautiful images and descriptions to effectively boost sales.
Brand Presentation: The entire user interface (UI) can be fully integrated with your brand logo, colors, and visual elements, making every screen interaction a platform for brand promotion and strengthening customer awareness.
Fast Food and Chain Restaurants: Significantly improves ordering efficiency during peak hours, reduces queues, and lowers labor costs.
Casual Restaurants and Cafes: Supports complex menu customization options (such as adding or subtracting ingredients, selecting flavors) to meet personalized needs, while the elegant interface enhances the ambiance of the space.
Food Courts and Group Catering: Centralized deployment alleviates ordering pressure and supports multi-store, multi-category display and payment.
Brand Flagship Stores: Highly customized hardware appearance and software interface become an important window to showcase your brand's technological sophistication and innovation.
Choosing our modular self-service ordering machine integrated solution means you've chosen a partner with both robust hardware capabilities and flexible software intelligence. We provide comprehensive support, from external protection to internal modules, from touch interaction to back-end management, to help your restaurant stand out in the digital competition and create a smoother, more autonomous, and more satisfying dining experience for your customers.
| LCD Panel Parameters | Screen Size | 32 inch | |
| Display area | 698(H) X 391.8(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 832 X 530 X 150mm | ||
| The Gross weight of Unit Package | 50kg | ||
