Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-SOK018
In today's digital age, self-service ordering kiosks in the catering industry are gradually becoming a new favorite, leading a transformation in consumption patterns. They not only provide customers with a convenient and efficient ordering experience but also bring numerous advantages to catering retail businesses, helping them stand out in fierce market competition.
The introduction of self-service ordering kiosks in the catering retail industry has greatly simplified the ordering process. Customers no longer need to queue and wait for waiters to take their orders; they can simply click on the machine to complete a series of operations, including browsing the menu, selecting dishes, placing an order, and making payment. This self-service ordering method not only saves customers' time but also effectively reduces errors that may occur with manual ordering, improving order accuracy and efficiency. For catering retail businesses, this means serving more customers faster during peak hours, increasing table turnover and operational efficiency, thereby increasing revenue.
![]()
Leveraging advanced data analytics technology, catering retail self-service ordering kiosks can provide personalized dish recommendations based on customers' historical ordering records and consumption habits. When customers stand in front of the machine to order, the screen automatically displays information such as dishes they might like, set meal combinations, and new product recommendations. This personalized service not only helps customers make ordering decisions faster but also increases their chances of discovering their favorite dishes, improving dining satisfaction. Furthermore, self-service ordering machines can interact with customers through membership systems, such as points redemption and coupon distribution, further enhancing customer stickiness and loyalty, and building a stable customer base for catering retail businesses.
![]()
The massive amounts of consumer data recorded by catering retail self-service ordering machines are a goldmine waiting to be tapped. Through in-depth analysis of this data, catering retail businesses can clearly understand customer taste preferences, consumption frequency, and consumption times, providing strong support for menu development, inventory management, and staff scheduling.
![]()
For example, if data shows a continuous increase in the order rate for a certain dish, the business can consider promoting it as a flagship product and adjust its ingredient procurement plan and kitchen production arrangements accordingly. Meanwhile, businesses can also rationally arrange staff shifts based on changes in customer traffic at different times, ensuring efficient service during peak hours, avoiding waste of human resources, and achieving refined management and operation.
| LCD Panel Parameters | Screen Size | 21.5 inch | |
| Display area | 476.5(H) X 268(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 585 X 380 X 110mm | ||
| The Gross weight of Unit Package | 50kg | ||
In short, self-service ordering machines in the catering retail industry not only bring customers a brand-new ordering experience but also open a door to efficient operation and precise marketing for catering retail businesses. In the future catering retail industry, it will undoubtedly become an indispensable and important component, continuously driving industry innovation and development, and helping businesses meet more challenges and opportunities.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
