Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-SOK016
In retail, catering, and other service industries, customer experience and operational efficiency are key factors determining business success. Faced with increasing customer traffic and service expectations, traditional manual checkout and ordering methods often become efficiency bottlenecks, leading to problems such as long queues, operational errors, and service delays. Smart self-service ordering terminals, with their high-definition touchscreen technology and optimized process design, are becoming a powerful tool for businesses to improve service quality and achieve efficient operations.
![]()
The device features a high-definition capacitive touchscreen with clear and detailed images and sensitive touch response. Users can easily complete operations such as ordering and payment through an intuitive graphical interface without complicated learning. Whether it's the elderly, children, or first-time users, everyone can quickly get started and enjoy a smooth and convenient self-service experience. The high-definition display not only improves visual comfort but also ensures that menus, prices, and prompts are clearly visible, reducing errors caused by unclear interfaces.
![]()
The core value of the 21.5-inch smart self-service ordering machine lies in significantly reducing service waiting time and improving overall operational efficiency. By integrating ordering and payment into a single self-service terminal, customers can complete the entire process independently, fundamentally avoiding congestion at traditional manual counters.
For example, during peak hours, a single device can process multiple orders in a short time, reducing the average checkout time from several minutes to tens of seconds. The system supports multiple payment methods and synchronizes with the back-end order management system in real time, ensuring accurate and fast transaction completion. This not only reduces the workload of cashiers but also allows customers to enjoy the convenience of queuing-free service, greatly improving customer satisfaction and store turnover.
![]()
The 21.5-inch smart self-service ordering machine features a flexible design that can be adapted to different store formats, spaces, and business needs. Whether it's a fast food restaurant, coffee shop, convenience store, shopping mall food court, or cinema concession stand, the device can quickly integrate into the operating environment and leverage its efficiency advantages. Its modular design also supports future expansion, such as integrating value-added services like membership systems, coupon redemption, and invoice printing, helping merchants build a smarter and more personalized service system.
![]()
The 21.5-inch smart self-service ordering machine is not just an application of technology, but also an upgrade in service philosophy. It lowers the barrier to entry through high-definition touch technology and breaks through efficiency bottlenecks with digital processes, helping merchants improve customer experience while optimizing manpower and reducing operating costs. In today's increasingly competitive business environment, investing in such an efficient and reliable self-service terminal is undoubtedly an important step for merchants towards intelligent and efficient operations.
| LCD Panel Parameters | Screen Size | 21.5 inch | |
| Display area | 476.5(H) X 268(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 585 X 380 X 110mm | ||
| The Gross weight of Unit Package | 50kg | ||
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
