Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-SOK012
In today's fast-paced life, the fast food industry faces the dual challenge of improving service efficiency while ensuring a positive customer experience. The 21.5-inch fast food ordering system, with its large screen display, intuitive interface, and rich functional expansion capabilities, has become an ideal choice for optimizing fast food restaurant operations. This article will explore how the 21.5-inch fast food ordering system can improve service levels and operational efficiency in the fast food industry, focusing on its unique advantages, innovative application scenarios, and practical operating experience.
The core mission of self-service checkout machines is to completely eliminate checkout queues. Customers use the device's built-in high-sensitivity scanner to scan product barcodes, and then quickly complete payment via mobile payment methods such as mobile phone scanning, facial recognition, or NFC. The entire process requires no employee intervention, reducing the average checkout time to less than one minute. This is especially suitable for customers buying small quantities of items and prioritizing efficiency, significantly improving shopping smoothness and satisfaction.
The device integrates the core hardware required for retail POS systems:
High-Definition Large-Size Touchscreen: Provides clear and intuitive operation guidance and information confirmation interface.
High-Sensitivity Scanner: Quickly and accurately recognizes 1D/2D barcodes.
Thermal Receipt Printer: Automatically prints a receipt after successful payment.
Wireless Antenna: Ensures stable Wi-Fi/4G network connectivity and supports real-time data synchronization and updates.
The device features an intelligent advertising carousel mode. In standby mode or during checkout intervals, the screen automatically loops preset advertising images or videos, covering content such as:
Store Promotions
New Product Recommendations and Brand Promotions
Member Discount Information
Public Welfare or Friendly Reminders
This function transforms previously idle terminals into 24/7 online digital billboards, continuously enhancing store marketing exposure and promotional effectiveness, and improving space efficiency without incurring additional costs.
By deploying unmanned self-service checkouts, merchants can:
Significantly reduce operating costs: Reduce reliance on cashiers and optimize manpower structure.
Improve operational efficiency: Achieve 24/7 unmanned checkout capability and extend effective service time.
Optimize customer experience: Provide autonomous, private, and convenient payment options, catering to digital consumption habits.
Collect consumer data: Accumulate transaction data to provide decision support for product selection, pricing, and promotions.
Unmanned self-service checkouts are not just checkout tools, but also key entry points for new retail stores to revolutionize efficiency, upgrade experience, and achieve digital management. They represent a shift from "people serving people" to "technology empowering people," helping merchants find the optimal balance between cost control and service quality, and confidently address the challenges and opportunities of the future retail market. Embracing unmanned self-service checkouts means choosing a smarter, more efficient, and more consumer-oriented future in retail.
| LCD Panel Parameters | Screen Size | 21.5 inch | |
| Display area | 476.5(H) X 268(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Intel Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 585 X 380 X 110mm | ||
| The Gross weight of Unit Package | 50kg | ||
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
