Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OLED-T48-WPXA
OLED self-emissive technology delivers rich and vibrant colors.
Transparent illumination ensures perfect image quality.
Ultra-high contrast ratio provides exceptional image depth, with pure blacks and brilliant highlights.
Lightning-fast refresh rate ensures lag-free viewing and eye-friendly operation.
Transparency enhances the integration of virtual displays, creating a more technologically advanced and harmonious aesthetic.
Professional display case design.
| 48-inch OELD display cabinet(ZXTLCD-T48-WPXA) | |
| LCD Panel Parameters | |
| Screen Size | 48 inch |
| Panel type | OLED |
| Resolution | 1920*540 |
| Brightness | 150-400cd/㎡ Automatic adjustment |
| Contrast Ratio | 100000:1 |
| Viewing angle(up/down/left/right) | 178°(H)/178°(V) |
| Response Time | 1ms(Gray To Gray) |
| Display color | 10bit(R),1.07 billon colors |
| Onboard interface | |
| Input Interface | USB*1 + HDMI*1 +DP*1+RS232*1 |
| Output interface | TBD |
| Touch Method | |
| Capacitive Touch screen | Default 10 points Capacitive Touch |
| Power Specifications | |
| Power supply | AC 100-240V |
| Total System Power Consumption | <200W |
| Machine Operating Parameters | |
| running time | 7*12h |
| Screen life | 30000h |
| Operating temperature | 0℃~40℃ |
| Operating Humidity | 20%~80% |
| structure | |
| Material | Aluminum+Tempered Glass |
| external dimensions | 1474*418*418(mm) |
| Overall dimensions | TBD |
| Installation Method | Integrated base |
| Net weight / Gross weight | TBD |
| Accessories | |
| Power cord, HDMI cable, remote control, certificate of conformity and warranty card | |
| other | |
| After-Sales Service | 1-Year Warranty |
