Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OLED-T77-RPXA
I. Product Highlights
77-inch Extra-Large Size: Breaking through traditional screen limitations, delivering a more immersive visual experience, suitable for high-end showrooms, shopping mall windows, science museums, and other scenarios.
OLED Self-Emitting Technology: Each pixel emits light independently, resulting in more realistic and delicate color reproduction, higher contrast, purer blacks, and a more transparent image.
High Transparency: With a screen transparency of over 45%, it clearly displays the content while allowing you to see the environment behind it, creating a highly technological feel.
Vertical Design: No additional stand required, saving space and facilitating easy movement and placement, suitable for various scenarios.
High Brightness and Wide Viewing Angle: Clear display even in bright environments, with a 178° wide viewing angle, providing a [sensitive word] visual effect from any viewing angle.
Multi-Touch: Supports multi-touch for human-computer interaction, enhancing user experience, suitable for interactive displays, education, and other fields.
Ultra-Thin Body: Slim and lightweight body, easy to install and transport.
Low Power Consumption and Long Lifespan: OLED technology features low power consumption and a long lifespan, making it energy-efficient and environmentally friendly.
II. Application Scenarios
High-end Exhibition Halls: Used to showcase corporate image, product information, corporate culture, etc., enhancing brand value.
Shopping Mall Windows: Used to display product information, promotional activities, etc., attracting customer attention and increasing sales.
Science and Technology Museums: Used to display scientific achievements, popular science knowledge, etc., enhancing interactivity and engagement.
Museums: Used to display cultural relics, historical culture, etc., enhancing the visitor experience.
Conference Centers: Used to display conference information, presentation content, etc., improving conference efficiency and effectiveness.
Others: Can also be applied to advertising media, stage performances, hotels and restaurants, etc.
| 77-inch vertical digital human device(ZXTLCD-T77-RPXA) | |
| LCD Panel Parameters | |
| Screen Size | 77 inch |
| Panel type | Transparent OLED |
| Resolution | 3840*2160 |
| Brightness | 200-600cd/㎡ Automatic adjustment |
| Contrast Ratio | 200000:1 |
| Viewing angle(up/down/left/right) | 178°(H)/178°(V) |
| Response Time | 0.1ms(Gray To Gray) |
| Display color | 10bit(R),1.07 billon colors |
| Onboard interface | |
| Input Interface | Type-c*1 USB*2 HDMI*3 RJ45*1 TOUCH USB*1 |
| Output interface | RS232 |
| Touch Method | |
| Capacitive Touch screen | Default 10 points Capacitive Touch |
| Power Specifications | |
| Power supply | AC 100-240V |
| Total System Power Consumption | <280W |
| Machine Operating Parameters | |
| running time | 7*12h |
| Screen life | 30000h |
| Operating temperature | 0℃~40℃ |
| Operating Humidity | 20%~80% |
| structure | |
| Material | Aluminum+Tempered Glass+Metal |
| external dimensions | 1045*602*2042(mm),The base is 307mm wide. |
| Overall dimensions | 2098*524*1230mm |
| Installation Method | Base installation |
| Net weight / Gross weight | 150/200KG |
| Accessories | |
| Power cord, remote control, certificate of conformity and warranty card | |
| other | |
| After-Sales Service | 1-Year Warranty |
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
