Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OLED030D004
See the Future, at a Glance
Self-emissive OLED Technology – Pixel-level independent control for stunning color and depth, blending virtual and reality
43% High Transmittance – The screen becomes nearly invisible, making content float in the real world
150,000:1 Ultra-high Contrast Ratio + 120% Wide Color Gamut – Deep blacks, vivid colors, and every detail revealed
178° Wide Viewing Angle – Consistent brightness and color from any angle
97% Extreme Screen-to-Body Ratio + Ultra-slim Integrated Body – A perfect fusion of technology and industrial design
10-point Capacitive Touch (optional) – Smooth human‑machine interaction for dynamic presentations
LGD‑certified OLED panel
Six‑layer burn‑in protection + automatic pixel refresh (OFF‑RS)
30,000 hours service life (dynamic content playback)
1‑year warranty with professional after‑sales support
| 30 Inch Transparent OLED Desktop Display | |
| LCD Panel Parameters | |
| Screen Size | 30 inch |
| Panel type | OLED |
| transmittance | 43%(Typ.) |
| Max Resolution | 1366×768 |
| Aspect Ratio | 16:9 |
| Brightness | 600/150 cd/m2 |
| Contrast Ratio | 150000:1 |
| Viewing angle(up/down/left/right) | R/L 120(min) U/D 120(min) |
| Response Time | 0.1ms(Gray To Gray) |
| Display color | 1.07B(10bit) |
| Onboard interface | |
| port | HDMI IN*1, DP IN*1, RJ45(RS232) IN*1, RJ45(RS232) OUT*1,USB*1 |
| Touch Method | |
| Capacitive Touch screen(Optional) | Default 10 points Capacitive Touch |
| Power Specifications | |
| Power supply | 100-240V~, 50/60Hz |
| Total System Power Consumption | ≈85W System Not Included |
| Machine Operating Parameters | |
| running time | 7*12h |
| Screen life | 30000h |
| Operating temperature | 0℃~40℃ |
| working humidity | 20%~80% |
| structure | |
| Material | Aluminum+Tempered Glass+Metal |
| external dimensions | 689mm×443.5mm×230mm Refer to the structural dimension drawings. |
| Package size | 750mm×550mm×270mm |
| Installation Method | Base Installation |
| Net weight | 15KG |
| Accessories | |
| Power Cord,Remote Control | |
| other | |
| After-Sales Service | 1-Year Warranty |
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
