Place of Origin:
ShenZhen, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OF430BM
Value and Trends of ZXTLCD Outdoor Digital Signage:
Outdoor digital signage features waterproof and dustproof capabilities.
The Exterior Electronic Message Boards is designed with outdoor standards such as waterproof, dust-proof, high-temperature resistance, and low-temperature resistance. This enables its application in various outdoor scenarios, including bus stops, communities, pedestrian streets, parks, and tourist attractions, while operating continuously for 24 hours.
Outdoor digital signage utilizes high-brightness LCD screens.
The high-brightness LCD screen displays clear, vibrant images that can attract people's attention from both near and far distances. Its high brightness ensures optimal visibility in outdoor environments, automatically adjusting to ambient light conditions, reducing power consumption, and minimizing light pollution.
Dynamic and diverse content display.
Outdoor LCD Advertising Signs can play text, images, and videos, with the option for split-screen displays. It brings static content to life and releases sound, quickly capturing the attention of passersby. The combination of audio and visuals greatly stimulates viewers' emotions and touches their hearts.
Various interactive query options.
When equipped with query software, outdoor digital signage can provide services such as news reading, information retrieval, and notifications to the public. It can also be installed with games, allowing people leisurely strolling or shopping to experience the joy of gaming.
| 43寸单机版户外一体机(风冷款)规格书(英文版) | ||
| Specications | ||
| The containment structure | The material and feature of shell | IP65 outdoor cabinet, 1.5mm zinc coated steel, waterproof and anti-dust design. |
| Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
| LCD Panel | Screen Size | 43 inch |
| Display area | 530mm(H) X 938mm(V) | |
| Aspect Ratio | 9:16 | |
| LCD Type | TFT-LCD | |
| Max Resolution | 1080 X 1920 | |
| Display color | 16.7M | |
| Brightness | 1500 cd/㎡ ~ 2000cd/㎡ | |
| Contrast Ratio | 1000:1 | |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° | |
| Response Time | 6ms | |
| Field Frequency | 60Hz | |
| Buit-in Media Player | Ads updated type | USB copy by manual operation |
| RAM | 2GB | |
| Flash memory card | 16GB | |
| Plug-and-Play | Plug-and-play /No windows OS, Auto loop play when power on | |
| Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
| Audio format | MP3, WMA | |
| Photo format | BMP, JPEG, PNG, GIF etx | |
| Interface | HDMI | 1 |
| USB | 2 | |
| SD cassette | TF(Micro SD )card, scalable 32G | |
| ECU | Switch power supply | Industrial Power supply |
| Waterproof speaker | High quality waterproof 10W speaker | |
| Thunder Preventer | The tree-level lightning protection | |
| Leakage protective device | Defend Electricity Leakage | |
| Timer | Set up on/off time on day/week/month | |
| Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
| Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
| Environment | Working temperature | below 40℃ ~ + 55℃ |
| Working humidity | 5% ~ 95% | |
| Working Voltage | AC 100 ~240v , 50Hz | |
| Max Power Consumption | 280W | |
| The dimension of machine | To be determined | |
| Outer Package size and Gross weight | ||
Wide range of applications.
Outdoor Electronic Marquee Signs can be applied to electronic signage at bus stops, enriching commuters' boring wait times with bus information and other engaging content. It can also be integrated into smart communities, enabling quick dissemination of notifications to residents, transforming traditional monotonous written notices. Additionally, it can enhance the image of hotels, stores, and other businesses, attracting customers and serving various purposes.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
