Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OD002
When a display screen is as thin as paper, approaching invisibility, it ceases to be an appendage to a space and becomes part of its narrative. Transparent OLED Signage embody this perfectly—thin and almost invisible, yet capable of projecting the most dazzling light and shadow. More importantly, we understand that every space is unique, therefore offering comprehensive customization from form to function, allowing technology to perfectly match your creativity.
![]()
The stunning clarity of Transparent OLED Signage stems from a revolutionary underlying physical structure:
Pixel-Level Self-Emitting Technology: The screen utilizes mature Organic Light-Emitting Diode (OLED) technology. Each pixel is independently configured with a light-emitting unit, capable of being turned on or off independently. When a pixel is off, it does not absorb any light, achieving true transparency and pure darkness at the physical level.
Precision Sandwich Structure: Its core is precisely encapsulated from a glass substrate, self-emissive materials, and a metal backplate. This structure ensures the screen's durability while minimizing thickness and weight, achieving a visual realm of "thin as paper, almost invisible."
![]()
We reject the "one-size-fits-all" approach. The appearance and form of our Transparent OLED Signage are fully customizable, providing solutions for almost all space types:
Six Core Solutions:
Desktop Solution: Placed on counters, display stands, or desks, it becomes a smart interactive terminal that doesn't take up visual space.
Floating Solution: Serves as a brand image wall, product display window, or information navigation screen, creating a stunning visual impact and attracting customers.
Suspended Solution: Hanging from the ceiling, it creates a futuristic visual focal point that appears to float in the air.
Lifting Solution: An integrated lifting design that hides when not in use and rises gracefully when needed, exuding a sense of ceremony.
Transparent Cabinet Solution: Combined with customized display cases, it allows products to be displayed surrounded by digital light and shadow.
Transparent Splicing Solution: Seamlessly splicing multiple screens creates a giant transparent visual wall, suitable for grand scenarios such as showrooms and command centers.
Diverse Styles: Whether you need vertical, desktop, height-adjustable, hanging, or splicing screens, we can provide customized products based on your space design, brand image, and functional requirements, ensuring that each screen is an organic extension of the space.
![]()
With comprehensive customization capabilities, Transparent OLED Signage can seamlessly integrate into and empower various high-end scenarios:
Retail Spaces: Custom-designed suspended transparent screens as atrium art installations, or desktop screens for AR makeup and try-on experiences.
Corporate Showrooms: Utilizing large-scale splicing solutions to showcase development history, or using integrated lifting systems to unveil strategies at important moments.
Cultural and Art Venues: Custom-designed uniquely shaped vertical screens as "digital guides" for cultural relics, or creating transparent interactive display cases.
High-End Offices: Embedding desktop screens into conference tables to achieve shared collaborative whiteboards and data visualization.
![]()
Choosing our Transparent OLED Signage customization service means you are choosing a technology integration approach that is entirely centered on you. We deliver more than just a screen; we deliver an "invisible" smart terminal that is deeply integrated into your space design, precisely serves your business goals, and can evolve with your needs.
| Display Size | 30 inches | ||
| Backlight Type | OLED | ||
| Display Resolution | 1366*768 | ||
| Display ratio | 16:9 | ||
| Brightness | 200-600d/mt Automatic Adjustment | ||
| Contrast ratio | 135000:1 | ||
Visibility |
178*/178 | ||
| Response time | 0.1ms(Gray To Gray) | ||
| Color Depth | 10bit(R),1.07 billon colors | ||
| Interface | |||
| Input Interface | USB*1+HDMI*1+DC*1 | ||
| Power Supply Parameters | |||
| Power Input | DC24V | ||
| Total Power Consumption | <90W | ||
| Operating Environment | |||
| Operating Time | 7*16h | ||
| Life Span | 3000h | ||
| Operating Temperature | 0°C~40°C | ||
| Operating Humidity | 20%~80% | ||
| Structure | |||
| Material | Aluminum Profile + Tempered Glass + Sheet Metal | ||
| Dimensions | 1225.4*699.7*29.5(mm), see structural dimension diagram for details | ||
| Packaging Dimensions | TBD | ||
| Installation Method | Wall-mounted installation | ||
| Net weight/Gross weight | 6kg/8KG | ||
| Accessory list | Base, adapter, HDMI cable, remote control, certificate of conformity, warranty card | ||
| Others | One year warranty | ||
