Display Smooth For Classroom Multi-touch Smart Interactive Whiteboard Interactive Flat Panel Price Wholesale LCD Touch Screen All in One
major function:
1.File management software, support multiple systems, U disk and other equipment documents for automatic classification, viewing, editing and other operations.
2.channel Settings, support the custom boot channel, support the channel channel name customization. Full channel annotation, support quick setting of writing pen color; annotate multiple pages to preview the annotated page at any time; annotate the page to quickly import the whiteboard software.
3.System optimization software, provide system overview, application software management, system memory optimization; support the monitoring and alarm of system information, ops computer, touch screen, temperature and screen.
4.Side shortcut menu, support calendar, timer, magnifying glass, curtain, camera, calculator, spotlight, compass and other small tools application, support custom addition; support browser, whiteboard, welcome template, file management and other system application software and third-party software custom display function common teaching and training meeting function.
Designed for ease of use, the interactive display ensures that teachers can focus on teaching, not troubleshooting.
Intuitive Touch and Writing: 20 points of touch let multiple users write, erase, and move content simultaneously without complicated toolbars. Object Awareness automatically detects fingers, pens, and palms for a seamless experience. Write directly into web browsers, PDFs, and Microsoft Office files with desktop software.
Hassle-Free Maintenance: Ready to use out of the box, with automatic over-the-air updates and scalable management through remote software. Comes with warranty-backed support, including expert help and advanced hardware replacement.
Personalized Access: Sign in securely with a Google or Microsoft account to access cloud storage, apps, bookmarks, and custom widgets—settings follow you to any compatible display.
|
name
|
size
|
65"
|
|
show
|
Display Area HV (mm)
|
1425mm ×803mm
|
|
optimum resolution
|
3840×2160 pixels
|
|
Refresh the frequency
|
60Hz
|
|
luminance
|
300-350cd/m2
|
|
contrast ratio
|
1200:1 / 5000:1 (OC)
|
|
Visual Angle
|
1780(H/V)
|
|
Show color
|
8bit 16.7M/1.07B (10bit)
|
|
backlight
|
DLED
|
|
colour gamut ntsc
|
72%
|
|
life span
|
For 50,000 hours
|
|
surface
|
Body material
|
Aluminum alloy face frame, oxidation sandblasting process
|
|
Front frame color
|
Black [standard], can be customized silver black or other colors
|
|
Front frame glass
|
Physical tempered grade 7 explosion-proof glass / anti-glare explosion-proof grade 7 tempered glass
|
|
Front box pen slot
|
The two magnetic grooves on the front
|
|
Touch parameters
|
Identification principle
|
Infrared recognition
|
|
Touch embedding mode
|
Built-in integrated type
|
|
The way of writing
|
Finger, touch pen or other 2mm non-transparent object (full screen writing)
|
|
Number of touch points
|
At 20 o'clock
|
|
Touch resolution
|
32767*32767
|
|
Touch precision
|
±1mm
|
|
Single refers to the response speed
|
＜8ms
|
|
Touch number
|
The theoretical number is infinite
|
|
drivers
|
System automatic identification, no drive
|
|
support system
|
windowsXP /7/8/10/11,Android,MacOS,Linux
|
|
working temperature
|
-10~+50 ℃
|
|
communication mode
|
USB 2.0/USB 3.0
|
|
Built-in system
|
scheme
|
Amlogic T982
|
|
CPU
|
Quad-core ARM Cortex-A55
|
|
GPU
|
Mali-G52 MP2(2EE)
|
|
basic frequency
|
1.9GHz
|
|
internal storage
|
4G DDR
|
|
memory
|
32GB (EMMC)
|
|
Wi-Fi
|
2.4GHz/5GHz
|
|
System version
|
Android 13.0
|
|
Front interface
|
Enter the port
|
USB 3.0×3
|
|
HDMI×1
|
|
TOUCH USB×1
|
|
Type-C×1
|
|
Prehole position
|
Auto photosensitive hole 1
|
|
Remote control receives the indicator light 1
|
|
key
|
Eight buttons
|
Switch, volume +, volume-, eye protection, recording screen, home page, setting, touch switch (single button optional)
|
|
The machine interface
|
Enter the port
|
RJ45:×1
|
|
TOUCH USB:×1
|
|
USB3.0:×1
|
|
USB2.0:×1
|
|
RS232:×1
|
|
HDMI IN:×1
|
|
AV IN:×2
|
|
Other ports
|
AV OUT :×1
|
|
Earphone:×1
|
|
SPDIF OUT:×1
|
|
Complete machine power consumption
|
The power of the machine
|
≤260W
|
|
OPS power
|
≤110W
|
|
working voltage
|
100~240V AC, 50/60Hz
|
|
Standby power consumption
|
≤0.5W
|
|
Sound channel stereo
|
2.0
|
|
Dual-channel power
|
20W / 8 Euro 2 speakers
|
|
work environment
|
service temperature
|
0~40℃
|
|
operation humidity
|
10%~90% RH
|
|
Storage temperature
|
-20~60℃
|
|
Store humidity
|
10%~90% RH
|
|
above sea level
|
5000 Meters
|
|
Size weight
|
Standard bare machine size length * width * height (mm)
|
1485×108×887
|
|
Camera bare machine size: length * width * height (mm)
|
1485×108×900
|
|
Overall machine package dimensions length * width * height (mm)
|
1600×200×1000
|
|
VESA stent hole position (mm)
|
400(V)×500(H)
|
|
Wall hanging thickness (mm)
|
23mm
|
|
net weight
|
33KG
|
|
rough weight
|
41KG
|
|
Single outlet wooden box size: length * width * height (mm)
|
16702651160 (with base support)
|
|
Weight (including wooden box)
|
70KG
|
|
Standard list
|
nameplate (neutral)
|
1 (affixed on the back of the whole machine)
|
|
QR code (Neutral)
|
1 (at bottom left of front box)
|
|
Accessory box (neutral)
|
×1
|
|
Power supply line is 1.8M
|
1 (98 inches standard with 3 m)
|
|
Certificate of qualification (neutral)
|
×1
|
|
Warranty Card (Neutral)
|
×1
|
|
Remote control (battery-free)
|
×1
|
|
Touch pen (magnetic suction)
|
×2
|
|
Wall-hanger (neutral)
|
×1
|
|
Optional list
|
HDMI line
|
×1
|
|
TOUCH USB Line
|
×1
|
|
Intelligent page turning pen
|
×1
|
|
Wireless screen casting device
|
×1
|
|
traversing carriage
|
×1
|
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
