Smart Electronic Board All In One Interactive Whiteboard Flat Panel for Education LT Meeting Room Classroom Smart Board Digital Display Interact Flat Panel 4K Touch
major function:
Multi-theme system theme, provide conference, education, science and technology, welcome template, enterprise, government, medical, education, advertising and other more than ten industry template applications, support multi-person sign-in, save, scan code sharing.
a variety of sound mode selection, provide the choice of sound device function, can choose the horn, USB microphone, etc., and support the equalizer function.
support USB device sharing, Android and computer switch at any time, use at any time, the system suspension menu, sidebar, can be switched according to user needs.
With 20 points of interaction, teachers and students can collaborate effortlessly. Touch recognition ensures pens write, fingers move, and palms erase seamlessly, allowing teachers to focus on teaching without technology distractions.
Natural Interaction: Write, move, and erase intuitively with no overlays required.
Intelligent Activation: Simply pick up a pen to start writing instantly.
Versatile Inking: Save your notes in PDF or Microsoft Office formats and use ink-to-text in any application.
Students can share ideas and classwork easily using app-based screen sharing. Teachers maintain control with touch functionality to connected Windows and Mac devices.
Embedded Platform: Teach without a computer—browse the web, use the digital whiteboard, and access cloud-stored documents.
Cross-Platform Support: Works effortlessly with Windows, Mac, and Chrome OS.
Effortless Connectivity: USB-C provides video, touch, and audio integration with a single cable.
|
name
|
size
|
86"
|
|
show
|
Display Area HV (mm)
|
1895mm ×1066mm
|
|
optimum resolution
|
3840×2160 pixels
|
|
Refresh the frequency
|
60Hz
|
|
luminance
|
300-350cd/m2
|
|
contrast ratio
|
1200:1 / 5000:1 (OC)
|
|
Visual Angle
|
1780(H/V)
|
|
Show color
|
8bit 16.7M/1.07B (10bit)
|
|
backlight
|
DLED
|
|
colour gamut ntsc
|
72%
|
|
life span
|
For 50,000 hours
|
|
surface
|
Body material
|
Aluminum alloy face frame, oxidation sandblasting process
|
|
Front frame color
|
Black [standard], can be customized silver black or other colors
|
|
Front frame glass
|
Physical tempered grade 7 explosion-proof glass / anti-glare explosion-proof grade 7 tempered glass
|
|
Front box pen slot
|
The two magnetic grooves on the front
|
|
Touch parameters
|
Identification principle
|
Infrared recognition
|
|
Touch embedding mode
|
Built-in integrated type
|
|
The way of writing
|
Finger, touch pen or other 2mm non-transparent object (full screen writing)
|
|
Number of touch points
|
At 20 o'clock
|
|
Touch resolution
|
32767*32767
|
|
Touch precision
|
±1mm
|
|
Single refers to the response speed
|
＜8ms
|
|
Touch number
|
The theoretical number is infinite
|
|
drivers
|
System automatic identification, no drive
|
|
support system
|
windowsXP /7/8/10/11,Android,MacOS,Linux
|
|
working temperature
|
-10~+50 ℃
|
|
communication mode
|
USB 2.0/USB 3.0
|
|
Built-in system
|
scheme
|
Amlogic T982
|
|
CPU
|
Quad-core ARM Cortex-A55
|
|
GPU
|
Mali-G52 MP2(2EE)
|
|
basic frequency
|
1.9GHz
|
|
internal storage
|
4G DDR
|
|
memory
|
32GB (EMMC)
|
|
Wi-Fi
|
2.4GHz/5GHz
|
|
System version
|
Android 13.0
|
|
Front interface
|
Enter the port
|
USB 3.0×3
|
|
HDMI×1
|
|
TOUCH USB×1
|
|
Type-C×1
|
|
Prehole position
|
Auto photosensitive hole 1
|
|
Remote control receives the indicator light 1
|
|
key
|
Eight buttons
|
Switch, volume +, volume-, eye protection, recording screen, home page, setting, touch switch (single button optional)
|
|
The machine interface
|
Enter the port
|
RJ45:×1
|
|
TOUCH USB:×1
|
|
USB3.0:×1
|
|
USB2.0:×1
|
|
RS232:×1
|
|
HDMI IN:×1
|
|
AV IN:×2
|
|
Other ports
|
AV OUT :×1
|
|
Earphone:×1
|
|
SPDIF OUT:×1
|
|
Complete machine power consumption
|
The power of the machine
|
≤400W
|
|
OPS power
|
≤110W
|
|
working voltage
|
100~240V AC, 50/60Hz
|
|
Standby power consumption
|
≤0.5W
|
|
Sound channel stereo
|
2.0
|
|
Dual-channel power
|
20W / 8 Euro 2 speakers
|
|
work environment
|
service temperature
|
0~40℃
|
|
operation humidity
|
10%~90% RH
|
|
Storage temperature
|
-20~60℃
|
|
Store humidity
|
10%~90% RH
|
|
above sea level
|
5000 Meters
|
|
Size weight
|
Standard bare machine size length * width * height (mm)
|
1953×108×1151
|
|
Camera bare machine size: length * width * height (mm)
|
1953×108×1164
|
|
Overall machine package dimensions length * width * height (mm)
|
2100×215×1300
|
|
VESA stent hole position (mm)
|
400(V)×800(H)
|
|
Wall hanging thickness (mm)
|
36mm
|
|
net weight
|
60KG
|
|
rough weight
|
76KG
|
|
Single outlet wooden box size: length * width * height (mm)
|
2270×275×1460
(With bottom support)
|
|
Weight (including wooden box)
|
110KG
|
|
Standard list
|
nameplate (neutral)
|
1 (affixed on the back of the whole machine)
|
|
QR code (Neutral)
|
1 (at bottom left of front box)
|
|
Accessory box (neutral)
|
×1
|
|
Power supply line is 1.8M
|
1 (98 inches standard with 3 m)
|
|
Certificate of qualification (neutral)
|
×1
|
|
Warranty Card (Neutral)
|
×1
|
|
Remote control (battery-free)
|
×1
|
|
Touch pen (magnetic suction)
|
×2
|
|
Wall-hanger (neutral)
|
×1
|
|
Optional list
|
HDMI line
|
×1
|
|
TOUCH USB Line
|
×1
|
|
Intelligent page turning pen
|
×1
|
|
Wireless screen casting device
|
×1
|
|
traversing carriage
|
×1
|
