32 Inch Custom Touch Screen Self-Service Kiosk for Payment Interactive Ordering

32 Inch Custom Touch Screen Self-Service Kiosk for Payment Interactive Ordering

32 inch touch screen kiosk

self-service payment kiosk

interactive ordering kiosk

Luogo di origine:

Guangdong, Cina

Marca:

ZXTLCD

Certificazione:

CE/Rohs/FCC

Numero di modello:

ZXTLCD-SOK320W003

Contattici
Richieda una citazione
Dettagli del prodotto
Dimensioni dello schermo:
32 pollici
tipo di pannello:
IPS di grado A+ originale BOE
Luminosità:
400 cd/㎡
Risoluzione:
1920X1080
Angolo di visione:
178°/178° (orizzontale/verticale)
Consumo energetico:
80 W
Temperatura operativa:
Da 0°C a 50°C
Materiale del mobile:
Cassa in metallo + vetro
Schermo tattile:
Touchscreen capacitivo a 10 punti
Lettore NFC/scanner/lettore QR:
Supporto, integrato
Stampante termica da 80 mm:
Supporto, integrato
Scanner del passaporto:
Opzionale
Installazione terminale POS:
Ripristina spazio
Alimentazione elettrica:
CA 100~240 V, 50 Hz-60 Hz
Applicazione:
Ospitalità, albergo e ristorazione
Evidenziare:
chiosco interattivo per ordini self-service, chiosco interattivo per ordini self-service, chiosco in
Evidenziare:

32 inch touch screen kiosk

,

self-service payment kiosk

,

interactive ordering kiosk

Termini di trasporto & di pagamento
Quantità di ordine minimo
1
Prezzo
Negoziabile
Imballaggi particolari
cassa di legno, cartone, flight case sono opzionali
Tempi di consegna
3-5 giorni lavorativi
Termini di pagamento
L/C,T/T,Western Union,MoneyGram
Capacità di alimentazione
2000 pezzi al mese
Descrizione di prodotto

32 Inch Custom Touch Screen Self-Service Kiosk for Payment Interactive Ordering



Against the backdrop of continuous upgrading in the catering and retail industries, the 32-Inch Touch Screen Self-Service Kiosk is gradually becoming a core device for the digital transformation of stores. Through deep integration of touch interaction and POS systems, it automates the entire process from ordering and payment to order management, significantly improving operational efficiency and optimizing customer experience, helping merchants gain an edge in fierce competition.


32-inch Wall-mounted self-service machine(With POS machine)
LCD Panel Parameters Screen Size 32 inch
Display area 698(H) X 391.8(V)mm
Aspect Ratio  16:9
LCD Type a-Si TFT-LCD
Max Resolution 1920 X 1080
Display color 16.7M , 72% NTSC
Brightness 400 cd/
Contrast Ratio  1200 :1
Viewing angle(up/down/left/right) 89/89/89/89 (Typ.)(CR≥10)
Response Time 20ms
LCD Panel Life(hrs) 60,000(hrs)
Field Frequency  60Hz
PCAP  Touchscreen Panel Parameters Touch style Projected Capacitive Touch screen
Touch points 10 points
Cover Glass Physical toughened Morse magnitude 7 explosion-proof
Anti-microbial protection and Shatterproof Protection
Optically bonded 3mm glass for low parallax
The glass transmittance >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88%
Response speed < 6ms
Accuracy of touch More than 90% of the touch area ±2mm
Touch ways Fingers, touch pen
Output format The coordinate output
Clicks time Unlimited
The smallest touch size 5mm
Long resistance Yes available
Touch Interfaces USB
Operating temperature & Humidity below10℃ ~ +50℃, ≤ 85%RH
Storage temperature & Humidity below20℃ ~ +60℃, ≤ 90%RH
Mini PC Parameters (Fan-less Industrial PC) CPU Intel Celeron J1900
RAM 8GB
SSD 64GB
WIFI 150Mbps 802.11n wifi integate
Network port RJ45, 10M/100M Adaptive Ethernet
Interface 2 * RJ45 GB Ethernet
2 * RS232 Serial Port
operating system Win10 or win11 optional
Onboard interface HDMI input 1
VGA input 1
DVI input 1
USB Type B or Any USB Type optional 1
Parts(Built-in) QR/Barcode Reader Can recognize 1D barcode and 2D barcode
Receipt Printer 80mm Thermal printer with cutter
Power Power supply AC 100V~240V, 50/60Hz
The Max power loss ≤ 45w
Standby power loss < 1W
Features Operating temperature  0℃ ~ 50℃
Storage temperature  below10℃ ~ +60℃
Accessories The length of Power Cable 1.5m
The length of HDMI Cable 2m
The length of USB-A to USB-B Cable 1.5m
Versatile Mounting Solution Wall Mounted with walll mount bracket
Stand Holder(Optional) Movable, can be with wheels on the base, height is adjustable
Package size Machine body size Customized
Net weight Customized
Unit Package size  650(H) ×160(W) × 1300(D) mm
The Gross weight of Unit Package  Approx. 20 kg –25 kg


I. User-Centric Interaction Design, Reshaping the Ordering Experience


Unlike traditional devices, the 32 Inch Touch Screen Self-Service Kiosk emphasizes user experience and interaction logic:


Intuitive Touch Operation: Smartphone-like interface design reduces the learning curve.


Graphical Menu Display: High-definition images and categorized navigation make selection easier.


Immersive Ordering Process: Reduces communication steps and improves ordering efficiency.


Multi-Language Support: Adapts to international scenarios and enhances service coverage.


Customers don't need to queue or communicate; they can complete their order in just a few steps, significantly improving the overall smoothness of the experience.


32 Inch Custom Touch Screen Self-Service Kiosk for Payment Interactive Ordering 0

32 Inch Custom Touch Screen Self-Service Kiosk for Payment Interactive Ordering 1


As the trends of smart retail and automation continue to advance, 32 Inch Touch Screen Self-Service Kiosks are transforming from "optional devices" into "core infrastructure." They not only optimize the customer experience but also reshape how stores operate. In the future, with the continuous integration of technology and various scenarios, these self-service terminals will continue to unleash greater commercial potential and become a significant force driving industry upgrades.


If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
