Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OLED-T30-CP6A
OLED self-emissive technology delivers rich and vibrant colors.
Transparent illumination ensures perfect image quality.
Ultra-high contrast ratio provides exceptional image depth, with pure blacks and brilliant highlights.
High-speed refresh rate ensures lag-free viewing and eye-friendly operation.
No backlight, eliminating light leakage.
Supports a 178° ultra-wide viewing angle.
Supports capacitive touch and multi-scenario applications on Windows and Android systems.
Transparency enhances the integration with virtual displays, creating a more technologically advanced and harmonious look.
Professional commercial display design for a more ergonomic appearance.
| 30-inch vertical transparent kiosk(ZXTLCD-T30-CP6A) | |
| LCD Panel Parameters | |
| Screen Size | 30 inch |
| Panel type | Transparent OLED |
| Resolution | 768*1366 |
| Brightness | 200-600cd/㎡ Automatic adjustment |
| Contrast Ratio | 135000:1 |
| Viewing angle(up/down/left/right) | 178°(H)/178°(V) |
| Response Time | 0.1ms(Gray To Gray) |
| Display color | 10bit(R),1.07 billon colors |
| Onboard interface | |
| Input Interface | HDMI*1,DP*1,RS232 |
| Output interface | RS232 |
| Touch Method | |
| Capacitive Touch screen | Default 10 points Capacitive Touch |
| Power Specifications | |
| Power supply | AC 100-240V |
| Total System Power Consumption | <280W |
| Machine Operating Parameters | |
| running time | 7*12h |
| Screen life | 30000h |
| Operating temperature | 0℃~40℃ |
| Operating Humidity | 20%~80% |
| structure | |
| Material | Aluminum+Tempered Glass+Metal |
| external dimensions | 607*296*1590(mm),The base is 307mm wide. |
| Overall dimensions | 1715*587*727mm |
| Installation Method | Base installation |
| Net weight / Gross weight | 35KG/55KG |
| Accessories | |
| Power cord, HDMI port, USB port, remote control, certificate of conformity and warranty card, instruction manual | |
| other | |
| After-Sales Service | 1-Year Warranty |
