Place of Origin:
Guangdong, China
Brand Name:
ZXTLCD
Certification:
CE/Rohs/FCC
Model Number:
ZXTLCD-OLED030V008
The 30-Inch Self-Illuminating OLED Transparent Display employs cutting-edge screen technology to seamlessly blend vibrant visuals with transparency. Unlike traditional displays, it requires no backlight and becomes completely transparent when not displaying content. This makes it an ideal choice for a wide range of innovative applications—such as retail showcases, museum exhibits, or advanced office environments—where it can superimpose digital information onto the physical objects situated behind it. Despite its transparency, the screen delivers high-resolution imagery with rich colors and high contrast, thereby enhancing both visual aesthetics and functional utility. An integrated i7 processor ensures rapid loading speeds, while connectivity is easily established via an HDMI cable. Functioning as a glass kiosk, this device serves as an elegant and futuristic interactive information hub that seamlessly integrates with its surroundings while delivering dynamic and captivating content.
|
display parameters |
||||
|
Panel size |
30 inches. |
Panel type |
OLED |
|
|
display area |
664.29Mm * 373.48mm |
external dimensions |
676.09Mm × 387.48mm × 1.6mm (width × height × thickness) |
|
|
transmittance |
43% |
viewing angle |
178 °, 178 ° |
|
|
static contrast |
100000:1 (Typ.) Transmission |
Dynamic Contrast |
200000:1 (Typ.) Transmission |
|
|
patchwork |
Unilateral 5.9mmm, bilateral 12mm, overall unilateral stitching 5.9/5 9/5.9/8.1 (left/right/top/bottom) |
screen scale |
16:9 |
|
|
brightness |
200-600 (nits) |
Best resolution |
1366*768 |
|
|
Screen life |
≥ 30000 hours |
power |
≤ 150W |
|
|
Display color |
10-Bit, 1.07B (1B = 1 billion) |
Speaker |
8Ω/5W * 2 |
|
|
screen gross weight |
Screen weight 1.04kg |
Gross weight of the whole machine |
to be determined |
|
|
environment |
Working temperature 1 ℃~ 45 ℃ |
working humidity |
30%~80% |
|
|
running time |
18 hours x 7 days |
Ambient height |
(Altitude) 0~ 5000m |
|
|
response time |
8ms |
working voltage |
100V-240VAC, 50/60Hz |
|
|
Fitting method |
frame sticker |
Fitting method (optional) |
Full fit |
|
|
Driver Board |
||||
|
input interface |
HDMI IN |
USB |
USB 2.0 |
|
|
DP |
DP IN |
weight |
0.4Kg |
|
|
Control signal IN |
RS232 serial port (RJ45) |
Control signal OUT |
RS232 serial port (RJ45) |
|
|
function |
With splicing function |
protect |
Anti-afterimage, anti-burn, repair function |
|
|
Touch screen parameters: capacitance optional |
||||
|
touch technology |
Capacitive touch technology |
positioning accuracy |
3Mm |
|
|
Installation method |
Built-in integrated |
writing method |
Finger ≥ 5mm |
|
|
touch points |
10 touch writing |
Writing screen medium |
5-8Mm tempered high transparency glass |
|
|
response speed |
≤ 5ms |
computer driven |
drive-free |
|
|
mode of communication |
USB |
service life |
≥ 60 million times |
|
|
printer configuration |
||||
|
Print method |
Thermal line printing |
Paper type |
Continuous thermal paper, die-cut label paper |
|
|
resolution |
203Dpi (8dot/mm) |
Paper width |
24-58Mm (adjustable) |
|
|
Print speed |
MAX.170mm/s |
roll diameter |
Max. 50mm |
|
|
effective print width |
48Mm |
paper thickness |
0.053-0.09mm(receipt)/0.10-0.15mm(label) |
|
|
interface |
Serial, USB |
Paper loading method |
Easy Loading Paper |
|
|
one-dimensional barcode |
UPC-A, UPC-E, EAN8, EAN13, code39, ITF, CODEBAR, CODE128, CODE93 |
Automatic cutter |
Full and half cuts (via instruction) |
|
|
2D barcode |
QR code, PDF417 |
Chinese |
GBK: 16x16, 24x24 |
|
|
power supply |
DC12-24V/2A (peak > 4A) |
Western |
ASCII: 8x16, 9x17, 9x24, 12x24 |
|
|
QR code configuration |
||||
|
image sensor |
640X480 CMOS |
Field of view angle
|
Horizontal 60 °, vertical 48 ° |
|
|
lighting |
White LED (6500K) |
Communication interface |
TTL/RS-232, USB, RS485
|
|
|
reading code system 2D |
PDF417, Data Matrix, QR Code |
Appearance dimension (mm)
|
64.8 (W) × 60.5 (D) × 32.7 (H) mm
|
|
|
reading code system 1D |
Interleaved 2 of 5, ISBN, Code 93, Code 11, UCC/EAN-128 GS1 Databar, Matrix 2 of 5, Industrial 2 of 5, Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Standard 2 of 5, MSI-Plessey, GS1composite code, etc |
interface
|
USB, TTL233, RS232, RS485 and other interfaces, Interface form: FPC, SH 1.0 connector, Mirco USB optional
|
|
|
reading accuracy |
≥ 5mil |
weight |
20G |
|
|
Alipay |
30-150Mm (based on the front end of the lens, the screen size of the mobile phone is 5.2 inches) |
fall |
Can withstand a 1.2-meter drop to the concrete floor |
|
|
Bus code |
50-120Mm (based on the front end of the lens, the screen size of the mobile phone is 5.2 inches)
|
working voltage
|
5V DC ± 10% (reserve 3.3-16V wide voltage input)
|
|
|
sign contrast |
≥ 20%
|
Rated current
|
(Typical) Less than 190mA (5V input) Less than 100mA (10V input)
|
|
|
barcode sensitivity |
Tilt ± 55 °, Deflect ± 55 °, Rotate 360 °
|
vibration
|
2000 G, 0.7 ms, half sinus, 3 axes
|
|
|
Card reader configuration |
||||
|
antenna energy output |
Antenna surface electromagnetic strength (Hmax) ≤ 7.5A/m rms |
Reading time |
< 1s |
|
|
Electromagnetic intensity at the maximum reading distance in the normal direction of the antenna surface (Hmax ≥ 1.5A/m rms) |
card reading distance |
0~ 3Cm |
||
|
operating frequency |
13.56MHz ± 7KHz |
interface |
USB2.0 |
|
|
relative humidity |
<90% |
Storage and transportation relative humidity |
20%~93% |
|
|
atmospheric pressure |
86Kpa~ 110Kpa |
Mean Time Without Failure (MTBF) |
> 5000h |
|
|
Power supply method |
USB powered |
weight |
< 0.37Kg |
|
|
Support for development languages |
C++, BS, C #, etc |
external dimensions |
190Mm (L) X125mm (W) X40mm (H) |
|
|
Applicable operating system |
Windows XP/7/8/10; Kydroid Desktop Operating System (Feiteng, Kunpeng, Loongson, HiSilicon Kirin, Shenwei, Haiguang, Zhaoxin, AMD64) V10: win the bidding Kirin Desktop Operating System (Feiteng, Kunpeng, Loongson, Shenwei, Haiguang, Zhaoxin): Tongxin Desktop Operating System (Feiteng, Kunpeng, Loongson, HiSilicon Kirin, Zhaoxin) V20; Hongqi Linux Desktop Operating System (Loongson, Shenwei); Kirin Xin'an Operating System (Feiteng, Kunpeng, Loongson, Shenwei, Haiguang, Zhaoxin); Puhua Desktop Operating System (Loongson, Shenwei); Ubuntu18.04 (X86); Cent0S 8 (x86) |
|||
|
PC configuration (optional) |
||||
|
main board |
Intel Core |
|||
|
CPU |
4th generation/6th generation/7th generation/8th generation/10th generation - Core i3/i5/i7 (optional) |
|||
|
Memory |
4G/8G/16G-DDR3 (optional) |
|||
|
Hard disk |
SSD120G/240G/480-HDD500G/1T/2T (optional) |
|||
|
nuclear display |
Intel HD Graphics 4000 |
|||
|
Backplane I/O |
1 × DC_IN power interface, 1 × HDMI interface, 1 × VGA interface, 2 × USB3.0 interface, 1 × LAN_RJ interface, 2 × USB2.0 interface, 1 × Mic (input), 1 × PHONE (output) |
|||
|
Operating System |
Windows 7/Windows 10 operating system |
|||
|
Android configuration (optional) |
||||
|
Main board model |
3568/3288/3588 |
|||
|
Memory |
2G/4G/8G optional |
|||
|
storage |
16G/32G/64G/128G optional |
|||
|
interface |
1 × USB2.0, 1 × USB3.0, 1 × HDMI_OUT, 1 × LAN_RJ, 1 × WIFI |
|||
|
Packing and packing list |
||||
|
Package size |
Honeycomb box: 93 * 71 * 179CM |
Air box: 65 * 66 * 168CM |
||
|
Weight information |
Bare metal weight: 55KG |
Packaging weight: Bare metal + air box: 100KG Bare metal + honeycomb box: 80KG |
||
|
name |
With PC/Android |
|
||
|
Specifications |
quantity |
Remarks |
||
|
transparent display |
30 inch OLED transparent screen |
1 piece |
|
|
|
system |
Customized according to actual needs (built-in) |
1 set |
|
|
|
remote control |
Universal version (without battery) |
1 |
|
|
|
Power cord |
National standard 1.5 meters |
Article 1 |
|
|
|
HDMI extension cable Note ② |
optional |
Article 1 |
|
|
|
Touch the USB extension cable Note ② |
optional |
Article 1 |
|
|
|
HDMI signal cable Note ② |
optional |
Article 1 |
|
|
|
Warranty card certificate |
Chinese version |
1 sheet |
|
|
|
Note: HDMI extension cable, HDMI cable and touch USB extension cable are optional items. The final packing list is subject to the actual shipment of the customer. You can choose whether to configure the extension cable according to customer needs. Note that the selection will incur corresponding costs. Please confirm the price for shipment. |
||||
