Name: 55 Inch Custom Shell Transparent Oled Display High Transparency Vertical 2x2 splicing model See Through Touchscreen
Brand: Shenzhen ZXT LCD Technology Co.,Ltd
SKU: ZXTLCD-OLED-055PS004
Availability: InStock

Haus > produits > Transparente OLED >

55 Inch Custom Shell Transparent Oled Display High Transparency Vertical 2x2 splicing model See Through Touchscreen

55 inch transparent OLED display

custom shell transparent touchscreen

vertical 2x2 splicing OLED

Herkunftsort:

Guangdong, China

Markenname:

ZXTLCD

Zertifizierung:

CE/Rohs/FCC

Modellnummer:

ZXTLCD-OLED-055PS004

Treten Sie mit uns in Verbindung

Fordern Sie ein Zitat

55 Inch Custom Shell Transparent Oled Display High Transparency Vertical 2x2 splicing model See Through Touchscreen

Produktdetails

Bildschirmgröße:

55 Zoll

Art der Hintergrundbeleuchtung:

OLED selbstleuchtend

Auflösung:

1920*1080

Aktualisierungsrate:

120Hz

Panel-Transparenz:

43%

Standardfarben:

1.07B 10Bit

Aussehen Farbe:

Weiß/Schwarz/Anpassung

Helligkeit:

400nits (Mitte 1 Punkt, typ.)

Kontrastverhältnis:

8ms

Betrachtungswinkel:

Mindestens 60/60/60/60

Audiosystem:

Eingebaute 10 WX 2-Lautsprecher

Integriertes WLAN:

150 Mbit/s 802.11n WLAN integriert

Betriebssystem:

Android oder Windows optional

Touchscreen-Typ:

Projizierter kapazitiver Touchscreen

Berührungspunkte:

10 Punkte

CPU:

Intel I9-14900KF-Prozessor der 14. Generation

RAM:

16 GB

SSD:

512 GB

Diskrete Grafikkarte:

12 GB GIGABYTE 4070

Eingangsspannung:

Wechselstrom 100–240 V, 50 Hz–60 Hz

Onboard-Schnittstelle:

1 x RJ45, 2 x HDMI, 4 x USB2.0

Prototyp:

Desktop / Standgerät / Interaktiv (optional)

Hervorheben:

55 inch transparent OLED display

custom shell transparent touchscreen

vertical 2x2 splicing OLED

Zahlungs-u. Verschiffen-Ausdrücke

Min Bestellmenge

Preis

Verhandlungsfähig

Verpackung Informationen

Holzkiste, Karton, Flightcases sind optional

Lieferzeit

3-5 Werktage

Zahlungsbedingungen

L/C, T/T, MoneyGram, Western Union

Versorgungsmaterial-Fähigkeit

2000 Stück pro Monat

Verwandte Produkte

55-Inch Transparent OLED Screen with High-definition Resolution, Touch Functionality, and ultra Design Transparent Display

Erhalten Sie besten Preis

A 55-inch transparent OLED mobile reception robot equipped with autonomous navigation, voice interaction, and facial recognition is suitable for reception scenarios.

Erhalten Sie besten Preis

55 Inch Custom Shell Transparent Oled Display High Transparency Vertical 2x2 splicing model See Through Touchscreen

Erhalten Sie besten Preis

55 Inch Vertical 2x1 splicing model Film Video Wall Ultra Thin Product launch event transparent oled screen

Erhalten Sie besten Preis

Treten Sie mit uns in Verbindung

Kontakt jetzt

Produkt-Beschreibung

55 Inch Custom Shell Transparent Oled Display High Transparency Vertical 2x2 splicing model See Through Touchscreen

Transparent screen, high-definition display, flexible splicing, unlimited expansion

The transparent splicing screen features a slim OLED module structure, significantly improving the overall architecture of traditional LCD displays.

It breaks through the traditional display playback form and broadens the application range of traditional displays.

Sponcing method: 2×2 splicing, that is, four 55-inch OLED transparent screens are spliced together in a 2x2 arrangement.

Sponcing effect: Through precise splicing technology, a seamless or near-seamless splicing effect is achieved, making the entire screen present a complete and continuous picture.

Installation and debugging: Gongxian Shengshi Technology provides installation and debugging services to ensure that the spliced screen can operate normally and present the best picture effect.

Transparent OLED Video Wall — Horizontal 2x2(ZXTLCD-OLED-055PS004)
Parameters
Panel	Size	55 inches
	Type	OLED panel technology
	Light transmittance	43%
	Dynamic contrast ratio	200000:1
	Aspect ratio	9:16
	Resolution	2160x3840
	Viewing angle	R/L 120(min) U/D 120(min)
	Brightness	600/200 cd/m² (Center 1point,typ)
	Number of pixels(HxVx3)	6220800
	Color gamut	90%
	Lifespan (typical value)	30,000 hours
	Operating time	18 hours/7 days (dynamic images only)
	Orientation	vertical orientation
	Refresh rate	120Hz
Interfaces	Input	HDMI Interfaces*2
		USB Interfaces*1
		Ethernet Port x1
	Output	Ethernet Port x1
Bezel Specification	Physical Seam	11.8mm
Function	Touch control	None/Capacitive (optional)
	Features	Transparent display, pixel-level self-controlling backlight, ultra-fast response
Power/Environment	Power supply	Operating power supply: AC100-240V, 50/60Hz
	Environment	Temperature: 0-40°C, Humidity: 10%-80%
Dimension	Display size	1378.1*2440(mm)
	Panel size	1378.1*2440(mm)
	Overall dimensions	1550*3070(mm)
Power Consumption	Typical value	760W
	DPM	3W
	Power off	0.5W
Packaging	Stand	Main unit box, cover plate, base
	Accessories	Remote control, power cord

55 Inch Custom Shell Transparent Oled Display High Transparency Vertical 2x2 splicing model See Through Touchscreen 0

55 Inch Custom Shell Transparent Oled Display High Transparency Vertical 2x2 splicing model See Through Touchscreen 1

If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
