55 Inch Vertical 2x1 splicing model Film Video Wall Ultra Thin Product launch event transparent oled screen

55 Inch Vertical 2x1 splicing model Film Video Wall Ultra Thin Product launch event transparent oled screen

55 inch transparent OLED screen

ultra thin video wall display

2x1 splicing OLED screen

Herkunftsort:

Guangdong, China

Markenname:

ZXTLCD

Zertifizierung:

CE/Rohs/FCC

Modellnummer:

ZXTLCD-OLED-055PS003

Treten Sie mit uns in Verbindung
Fordern Sie ein Zitat
Produktdetails
Bildschirmgröße:
55 Zoll
Art der Hintergrundbeleuchtung:
OLED selbstleuchtend
Auflösung:
1920*1080
Aktualisierungsrate:
120Hz
Panel-Transparenz:
43%
Standardfarben:
1.07B 10Bit
Aussehen Farbe:
Weiß/Schwarz/Anpassung
Helligkeit:
400nits (Mitte 1 Punkt, typ.)
Kontrastverhältnis:
8ms
Betrachtungswinkel:
Mindestens 60/60/60/60
Audiosystem:
Eingebaute 10 WX 2-Lautsprecher
Integriertes WLAN:
150 Mbit/s 802.11n WLAN integriert
Betriebssystem:
Android oder Windows optional
Touchscreen-Typ:
Projizierter kapazitiver Touchscreen
Berührungspunkte:
10 Punkte
CPU:
Intel I9-14900KF-Prozessor der 14. Generation
RAM:
16 GB
SSD:
512 GB
Diskrete Grafikkarte:
12 GB GIGABYTE 4070
Eingangsspannung:
Wechselstrom 100–240 V, 50 Hz–60 Hz
Onboard-Schnittstelle:
1 x RJ45, 2 x HDMI, 4 x USB2.0
Prototyp:
Desktop / Standgerät / Interaktiv (optional)
Hervorheben:

55 inch transparent OLED screen

,

ultra thin video wall display

,

2x1 splicing OLED screen

Zahlungs-u. Verschiffen-Ausdrücke
Min Bestellmenge
1
Preis
Verhandlungsfähig
Verpackung Informationen
Holzkiste, Karton, Flightcases sind optional
Lieferzeit
3-5 Werktage
Zahlungsbedingungen
L/C, T/T, MoneyGram, Western Union
Versorgungsmaterial-Fähigkeit
2000 Stück pro Monat
Produkt-Beschreibung
55 Inch Vertical 2x1 splicing model Film Video Wall Ultra Thin Product launch event transparent oled screen

A 2x1 transparent OLED display combines two transparent OLED screens to form a 2x1 display area. Transparent OLED is an emerging display technology characterized by high brightness, high contrast, and wide viewing angles, while allowing the viewer to see objects behind the screen.


By combining two transparent OLED displays, a larger display area can be achieved, providing users with a richer visual experience. This splicing method allows for the creation of larger displays while maintaining transparency throughout the entire area, enabling the displayed content to blend seamlessly with the environment and create a more immersive effect.


The 2x1 transparent OLED display has applications in various fields. For example, in the retail industry, it can be used as a product display window to attract customer attention.

In the smart home field, it can be applied to display panels or mirrors to provide information display and intelligent control functions. In the advertising industry, the 2x1 transparent OLED display can be used for outdoor billboards to attract more attention.


Transparent OLED Video Wall — Vertical 2x1 Configuration(ZXTLCD-OLED-055PS003)
Parameters

    Panel

Size 55 inches
Type OLED panel technology
Light transmittance 43%
Dynamic contrast ratio 200000:1
Aspect ratio 16:9
Resolution 1080*3840
Viewing angle  R/L 120(min) U/D 120(min)
Brightness 600/200 cd/m² (Center 1point,typ)
Number of pixels(HxVx3) 6220800
Color gamut 90%
Lifespan (typical value) 30,000 hours
Operating time 18 hours/7 days (dynamic images only)
Orientation vertical orientation
Refresh rate 120Hz
Interfaces Input HDMI Interfaces*2
USB Interfaces*1
Ethernet Port x1
Output Ethernet Port x1
Bezel Specification Physical Seam 11.8mm
Function Touch control None/Capacitive (optional)
Features Transparent display, pixel-level self-controlling backlight, ultra-fast response
Power/Environment Power supply Operating power supply: AC100-240V, 50/60Hz
Environment Temperature: 0-40°C, Humidity: 10%-80%
Dimension Display size 692*2387(mm)
Panel size 699.35*2443(mm)
Overall dimensions 806*2620(mm)
Power Consumption Typical value 380W
DPM 3W
Power off 0.5W
Packaging Stand Main unit box, cover plate, base
Accessories Remote control, power cord

55 Inch Vertical 2x1 splicing model Film Video Wall Ultra Thin Product launch event transparent oled screen 0

55 Inch Vertical 2x1 splicing model Film Video Wall Ultra Thin Product launch event transparent oled screen 1


If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
